LEMO 5-Contact Circular Panel Mount Socket, Female, 12.6 mm, IP50, 1B Series, Brass, Push Pull, EPG.1B.305.HLN

The LEMO EPG.1B.305.HLN Circular Connector is engineered for reliable panel mount installations in industrial, laboratory, and electronic environments. This connector features 5 contacts with a female interface, optimized for secure and efficient signal or power transmission in automation and instrumentation systems.

With a robust brass housing and gold over nickel plated contacts, it ensures maximum electrical conductivity and resistance to corrosion, supporting longevity in challenging industrial conditions. The connector's 12.6 mm form factor is designed for PCB mounting, offering right-angle orientation for efficient integration into equipment enclosures and control panels.

Rated for 1550 V and up to 4.5A current, the EPG.1B.305.HLN guarantees dependable performance across high voltage and high-current applications. The push-pull mating mechanism offers fast, secure connections while facilitating frequent plugging and unplugging without wear. Its IP50 rating protects against dust, making it ideal for environments where partial dust ingress is permissible, such as factory floors or test labs.

Its solder termination allows precise, permanent connection to circuit boards, further enhancing reliability. The connector operates from a minimum temperature of -55°C up to 250°C, making it suitable for both low and high-temperature applications. Beryllium alloy contact material ensures optimum electrical interface, with pole format and shell size supporting standardized industrial connector requirements.

Typical use cases include industrial machinery, laboratory instrumentation, automation control systems, PCB assemblies, robotics, and test equipment requiring durable, high-performance connectors for panel mounting.

Panel mount socket with 5 contacts suitable for electronic and industrial applications. Features female plug interface and right angle orientation for robust PCB integration. Body made of durable brass with gold over nickel contact plating for enhanced conductivity.

Rated for IP50 ingress protection and suitable for operating voltages up to 1550 V. Push-pull mating mechanism ensures easy and reliable connection. Designed for solder termination and maximum operating temperature of 250°C.

Complies with stringent requirements for quality, utilizing beryllium alloy contact material. Operates from -55°C minimum up to 250°C maximum, ideal for demanding environments. Browse more Industrial Circular Connectors from LEMO and related components on EnvMart for advanced electronic and automation solutions.
