Honeywell Differential Pressure Sensor Surface Mount 6 Pin, ±0.25% Accuracy, 5V, ABPMRRV001PDAA5

The Honeywell ABPMRRV001PDAA5 is a precision differential pressure sensor designed for accurate monitoring of pressure differentials in electronic and industrial applications. This sensor features a surface mount technology (SMT) package with six pins, making it ideal for automated assembly lines and integration with modern printed circuit boards. Its ±0.25% accuracy ensures that it delivers precise measurements even in demanding operating environments.

This sensor is equipped with dual radial barbed ports, allowing it to measure the pressure difference between two separate flows. The broad operating temperature range from -40°C to 85°C makes the device suitable for diverse environments, from medical and laboratory climate control to heavy-duty industrial process regulation.

A supporting supply voltage from -0.3V up to 5V allows engineers the flexibility to implement the sensor in both low-voltage and higher voltage systems. The sensor’s rapid update capability - ratiometric analogue output at 1kHz and digital output at 2kHz - provides real-time feedback for dynamic control systems, helping deliver fast and reliable system responses.

The ABPMRRV001PDAA5 comes in a compact 7.3 mm by 10.63 mm form factor. Its small footprint is ideal where PCB space is limited, yet high measurement precision and stable performance are critical. Typical use cases include pressure monitoring in medical ventilator and oxygen concentrator systems, HVAC control, pneumatic regulation, laboratory instrumentation for blood analysis, process monitoring in industrial facilities, and flow/pressure regulation in commercial appliances such as washing machines and coffee equipment.

Available in a moisture-protected version, this sensor offers the option to handle either non-corrosive dry gases or, with its silicone-based gel protection, compatible liquid media and condensation. It offers digital communication via I2C or SPI for easy integration into digital systems and supports analogue output for legacy compatibility. The total error band within ±1.5% of full scale ensures reliable system design and safety margins.

Its SMT package ensures reliable soldering and long-term performance in mass production. The device’s versatility, accuracy, and robust construction make it a standard choice for advanced sensing applications in commercial, industrial, and medical electronics.

This sensor is a reliable building block for next-generation electronic devices where miniature size, segmented pressure measurement, and repeatable accuracy are paramount. Explore more advanced sensing solutions in our Pressure Sensors section or browse the full catalog of Honeywell engineered components for your application needs on EnvMart.
