XP Power FIHAA03C1F EMI Filter 3A 264V AC Chassis Mount, Dual Stage, Quick Connect, 0 - 400Hz

The XP Power FIHAA03C1F is a professional EMI filter designed for power line noise suppression in demanding industrial and electronic systems. Featuring a high attenuation dual stage filter and a robust chassis mount design, this unit is engineered to effectively minimize conducted electromagnetic interference across a wide spectrum of frequencies.

Built with a shielded metal body and equipped with 6.3 x 0.8mm Faston quick connect terminals, the filter enables straightforward installation, maintenance, and reliable grounding. Its compact footprint - measuring just 52mm in length, 48mm in depth, and 30mm in height - makes it ideal for restricted equipment enclosures and panel integration where space is at a premium.

Rated for up to 3A maximum continuous current and 264V AC voltage, the FIHAA03C1F supports both low and high power application environments. The filter’s wide operating frequency specification (0Hz to 400Hz) ensures compatibility with single phase AC systems in industrial, laboratory, ITE, and commercial equipment. An integrated bleed resistor assists in safely discharging filter capacitors after power is removed, improving maintenance and operator safety.

With a broad operating temperature range from -40°C to +110°C, full power operation up to +50°C, and leakage current rated at 600μA, this filter is suitable for use within class I appliances, adhering to modern safety requirements. The unit is constructed to withstand challenging environmental and thermal conditions, maintaining reliable performance in both hot and cold climates.

Applications include industrial automation cabinets, laboratory instrumentation, medical and commercial electronics, HVAC controls, and any panel-mounted system requiring superior EMI suppression and compliance. Integration is simplified by its compact size and Faston connectors, reducing downtime in both new builds and maintenance upgrades.

For engineers and system designers seeking a durable, dual stage EMI filter, the XP Power FIHAA03C1F delivers stable performance, ease of installation, and robust safety features, making it a valuable addition to industrial electrical panels and equipment.

Provides high attenuation dual stage EMI filtering for industrial and commercial electronic applications. Rated for 3A maximum current at up to 264V AC, supporting wide-ranging input voltages. Chassis-mounted metal enclosure ensures robust installation and effective grounded shielding.

Features 6.3 x 0.8mm Faston quick connect terminals for convenient wiring and maintenance. Wide operating frequency range from 0Hz to 400Hz, suitable for various AC power systems. Integrated bleed resistor safely discharges filter capacitors when disconnected.

Operates reliably from -40°C up to 110°C, allowing use in extreme environments. Leakage current rated at 600μA, ensuring compliance with class I appliance safety requirements. Compact size: 52mm length, 48mm depth, and 30mm height for space-saving installations.

Country of origin: China; suitable for global industrial deployments. Explore more XP Power EMI noise filters and advanced industrial electronic filtering solutions in the EnvMart category browsing.
