Eaton 50A NH1 Centred Tag Blade Fuse 690V AC Fast Acting 170M3809D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 690V ac |
| Brand | Eaton |
| Height | 68mm |
| Length | 64mm |
| Model | 170M3809D |
| Width | 40mm |
| Overall Length | 135mm |
| Current Rating | 50A |
| Series | Bussmann |
| Fuse Type | Blade |
| Standards/Approvals | CSA, UL, IEC, CE |
| Fuse Size | NH1 |
| Tag Width | 20mm |
| Application Category | aR |
| Tag Type | Blade |
Key Features
- Rated for 50A current and 690V AC operation.
- NH1 size and blade/tag type design for reliable panel fitment.
- Fast acting with aR breaking characteristic for protection of semiconductors.
- High rupture capacity and dual indicator for enhanced safety and status visibility.
- Constructed with robust materials, suitable for demanding electrical environments.
- Tag width of 20mm, overall length 135mm, height 68mm, width 40mm.
- Complies with CSA, UL, IEC, CE standards for global compatibility.
- Ideal for protection in industrial, automation, and electrical power distribution panels.
Product Description
The Eaton 170M3809D is a high-quality, centred tag blade fuse engineered for safe and efficient overcurrent protection in electrical installations and automation systems. Featuring a 50A current rating and 690V AC voltage rating, it is designed for use in demanding industrial environments where reliable protection of sensitive equipment and semiconductors is critical.
This NH1 size fuse utilizes a blade/tag connection with a 20mm tag width, ensuring secure placement in fuse holders or distribution boards. Its fast acting ('aR' application category) characteristic makes it especially suited for the protection of power semiconductors such as diodes, thyristors, and variable speed drives, rapidly disconnecting circuits during fault conditions to minimize equipment damage.
The product incorporates a high rupture capacity, enabling safe interruption of high fault currents without endangering the installation. A dual indicator system improves maintenance and operational safety by providing a visual cue of fuse status. The fuse's compact body, measuring 135mm in overall length, 68mm height, and 40mm width, facilitates integration within standard NH1 panel cutouts.
Complying with rigorous international safety standards including CSA, UL, IEC, and CE, this fuse supports global deployment in industrial, commercial, and automation settings. Typical use cases include utility panels, motor control centers, power conversion, and heavy-duty industrial process equipment where rapid fault protection for electronic components is required.
The Eaton 170M3809D offers durable construction, enhanced by live gripping lugs for secure handling during installation and replacement. Its high-speed performance, safety features, and robust certification make it a preferred choice for electrical engineers and maintenance professionals.
Explore more Eaton industrial fuses and electrical protection solutions within the EnvMart Electrical Fuse category for compatible and related products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a voltage rating of 690V AC, making it suitable for high-voltage applications.
The Eaton 170M3809D is rated for a current of 50A, providing reliable overcurrent protection.
It has an overall length of 135mm, a height of 68mm, and a width of 40mm, with a tag width of 20mm.
This model is a blade fuse, specifically designed in the NH1 size with a centred tag type connection.
It complies with CSA, UL, IEC, and CE standards, ensuring global compatibility and safety in various applications.
The fuse falls under the 'aR' application category, which indicates it is fast acting and suitable for protecting semiconductors.
The dual indicator system provides a visual cue of the fuse status, improving maintenance and operational safety.
The high rupture capacity allows the fuse to safely interrupt high fault currents without compromising the installation's safety.
This fuse is manufactured in India, ensuring compliance with international standards.
It is ideal for use in industrial, automation, and electrical power distribution panels, particularly for sensitive equipment.
The fuse is designed with live gripping lugs that enhance secure handling during installation and replacement.
The overall length of this model is 135mm, which fits standard NH1 panel cutouts.
