Lubi 3 HP Three Phase Vertical Multi-stage Centrifugal Pump, MVRT 2-18

Lubi MVRT 2-18 3 HP Three Phase Vertical Multi-stage Centrifugal Pump is a high-efficiency solution for industrial, commercial, and municipal water supply systems requiring reliable, high-head, and clean liquid transfer. Designed with a close-coupled configuration, it provides a compact footprint for straightforward installation in limited or existing spaces.

Key wetted parts like impellers, guide vanes, bowl casing, and pump jackets are manufactured from AISI 304 stainless steel, while the pump shaft utilizes AISI 316 stainless steel, ensuring long-lasting performance, corrosion resistance, and suitability for a broad range of industrial fluids. The pump is equipped with a maintenance-free mechanical shaft seal and features radial suction at the bottom and radial discharge at the top for efficient inline piping.

• Features robust stainless steel construction with AISI 304 and AISI 316 components for superior durability and corrosion resistance.
• Delivers a power output of 2.2 kW (3 HP), suitable for demanding fluid transfer tasks.
• Head range from 163 to 79 meters and discharge range between 16.7 and 58.3 LPM to cover both low and high-head installations.
• Features a compact, close-coupled design for space-saving and easy installation, even in restricted locations.
• Equipped with a maintenance-free mechanical shaft seal to minimize downtime and servicing requirements.
• Inlet and outlet ports of 32 mm provide efficient flow handling and standardized piping compatibility.
• Operating liquid temperature range from 0°C to +90°C, enabling use in various industrial processes and water systems.
• Supports ultra-filtration, reverse osmosis, booster pressure, washing, sprinkler, and irrigation systems.
• Capable of handling clean, non-explosive liquids; verify compatibility for aggressive media.
• Includes oval flanges for easy installation and serviceability in demanding industrial environments.

This versatile centrifugal pump is ideal for use in ultra-filtration, reverse osmosis, domestic and industrial pressure boosting, hydro-pneumatic, sprinkler, irrigation, and various high-head duty conditions. Its design ensures stability, durability, and long service life, making it a preferred choice for water treatment, agricultural, laboratory, and manufacturing facilities. Browse more Lubi pumps and multi-stage centrifugal pumps in the Vertical Multistage Pumps category on EnvMart.
