Lubi 3 HP Three Phase Vertical Multi-stage Centrifugal Pump, MVRT 4-12
Specifications
| Country of Origin | India |
|---|---|
| Motor Power | 3 HP |
| Brand | Lubi |
| Power | 2.2 kW |
| Phase | Three Phase |
| Model | MVRT 4-12 |
| Application | Ultra-filtration, RO, pressure boosting, cleaning, irrigation |
| Weight | 32.5 kg |
| Liquid temperature range | 0–90 °C |
| Discharge Range | 31.7–131.7 LPM |
| Pump Type | Vertical Multi-stage Centrifugal |
| Seal Type | Mechanical, maintenance-free |
| Frame Size | 90 |
| Delivery Size | 32 mm |
| Suction Size | 32 mm |
| Head Range | 111–43 m |
| Shaft Material | AISI 316 Stainless Steel |
| Product Condition | New |
| MPN | MVRT 4-12 |
| Operating Ambient Temperature | +50 °C (max) |
| Material (Wetted Part) | AISI 304/316 Stainless Steel |
Key Features
Lubi MVRT 4-12 3 HP Three Phase Vertical Multi-stage Centrifugal Pump engineered for high head applications in industrial, commercial, and water treatment systems.
- Equipped with a powerful 3 HP (2.2 kW) three phase motor for reliable performance.
- Vertical multistage centrifugal design offering head range from 111 to 43 meters.
- Delivers discharge between 31.7 to 131.7 liters per minute for versatile applications.
- Constructed with robust stainless steel AISI 304/316 components for enhanced durability.
- Features radial suction at the bottom and radial discharge at the top for compact installation.
- Fitted with a maintenance-free mechanical shaft seal for trouble-free operation.
- Suitable for ultra-filtration, reverse osmosis, pressure boosting, cleaning, irrigation, and hydro-pneumatic systems.
- Designed for clean, non-explosive, non-viscous liquids without solids.
- Operating ambient temperature up to +50°C and liquid temperature from 0°C to +90°C.
- Frame size 90, delivery and suction port size 32 mm each; weight 32.5 kg.
Product Description
Lubi MVRT 4-12 3 HP Three Phase Vertical Multi-stage Centrifugal Pump is an advanced high head liquid handling solution for demanding industrial, water treatment, commercial, and municipal applications. This non-self priming, vertical, multistage centrifugal pump features a 2.2 kW (3 HP) close-coupled three phase motor, delivering a head range from 111 to 43 meters and discharge capacity of 31.7 to 131.7 LPM.
Constructed using premium stainless steel AISI 304 for impellers, guide vanes, bowl casing, and pump jacket, with the pump shaft built from AISI 316 stainless steel, the MVRT 4-12 offers excellent corrosion resistance and longevity across challenging environments. Its compact frame (size 90), radial suction and discharge design, and oval flanges simplify installation and servicing even in confined spaces.
- Power: 3 HP (2.2 kW), three phase.
- Head range: 111-43 m; discharge: 31.7-131.7 LPM.
- Frame size: 90, delivery and suction size: 32 mm.
- Pump and motor are close coupled for space-saving installations.
- Maintenance-free mechanical shaft seal ensures reliable, leak-free performance.
- Operates efficiently for clean, thin, non-explosive liquids.
- Highly suitable for ultra-filtration, reverse osmosis, pressure boosting in water supply, cleaning, hydro-pneumatic, sprinkler, and irrigation systems.
- Certified to operate at ambient temperatures up to +50°C and liquid temperatures from 0°C to +90°C.
Industrial use cases: manufacturing, construction, commercial building services, water purification, agriculture, and hydro-pneumatics.
Set your project up for success—browse more high performance Lubi pumps and motors in EnvMart’s Vertical Multistage Pumps section.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Lubi MVRT 4-12 pump is powered by a 3 HP (2.2 kW) three phase motor, ensuring reliable performance for various applications.
This pump offers a head range from 111 to 43 meters, making it suitable for high head applications.
The Lubi MVRT 4-12 is constructed with high-quality stainless steel AISI 304 for impellers and bowl casing, and AISI 316 for the pump shaft, ensuring durability and corrosion resistance.
The pump is designed for clean, non-explosive, non-viscous liquids without solids, making it ideal for applications like ultra-filtration and reverse osmosis.
The Lubi MVRT 4-12 can deliver a discharge range of 31.7 to 131.7 liters per minute, suitable for various applications.
The Lubi MVRT 4-12 pump weighs 32.5 kg, which makes it manageable for installation and servicing.
The pump operates efficiently at ambient temperatures up to +50°C and liquid temperatures from 0°C to +90°C.
Yes, the Lubi MVRT 4-12 features a maintenance-free mechanical shaft seal, ensuring reliable and leak-free operation.
This pump is suitable for ultra-filtration, reverse osmosis, pressure boosting, cleaning, irrigation, and hydro-pneumatic systems.
The Lubi MVRT 4-12 features a compact design with radial suction and discharge, allowing for easy installation even in confined spaces.
