Hanna HI1000 Series Process Digital pH Probe-50m (164.0')-HT - High Temperature-Ceramic
Specifications
| Country of Origin | India |
|---|---|
| Measurement Range | LT: 0–12 pH, HT: 0–14 pH, HF: 0–10 pH |
| Body Material | PVDF |
| Operating Temperature | -5 to 100 °C |
| Outer Diameter | 22.5 mm |
| Model | HI1016-3850 |
| Cable Length | 50 m |
| Temperature Sensor | Pt100 |
| Max. Pressure | 6 bar 87 psi |
| Connector Type | Direct wire connection |
| Reference Cell Type | Double Junction |
| Tip / Shape | flat |
| Matching Pin | yes |
| Glass Type | LT, HT, or HF (based on configuration) |
| Electrolyte | Polymer |
| Product Condition | New |
| MPN | HI1016-3850 |
| Body Length / Overall Length | 140 mm |
| Reference Junction | Ceramic |
Key Features
Process Digital pH Probe HI1016-3850 is an advanced high-temperature pH sensor with a 50-meter cable, designed for industrial applications and compatible with the HI510 Universal Process Controller.
- PT100 temperature sensor is integrated for accurate temperature compensation.
- Constructed with chemically resistant PVDF body and robust 3/4” NPT threaded mounting for durability and flexible installation.
- Equipped with a ceramic reference junction for reliable operation and measurement stability in aggressive environments.
- Supports three glass configurations: LT (low temperature), HT (high temperature), and HF (hydrofluoric acid), for versatile process needs.
- Digital RS485 output ensures immunity to electrical interference during data transmission.
- Double-junction reference cell extends probe lifespan in challenging conditions.
- Measures pH from 0–14 (HT glass), with maximum pressure support up to 6 bar (87 psi).
- Flat tip and polymer electrolyte provide high performance for industrial process control.
- Direct wire connection enables streamlined integration into process automation systems.
- Suitable for industrial, laboratory, and water treatment process monitoring.
Product Description
The Process Digital pH Probe HI1016-3850 is an industrial-grade, high-temperature pH sensor designed to deliver precise and stable pH measurements in demanding process applications. This robust probe features a chemically resistant PVDF body, a ceramic junction, and an integrated PT100 temperature sensor for highly accurate compensation. With a 140 mm body length and a 50m integrated cable, it provides flexible mounting, utilizing a 3/4” NPT threaded connection for in-line or submersion installation.
Engineered for versatility, the HI1016-3850 supports three specialized glass types—LT for low temperature (–5 to 80 ºC), HT for high temperature (0 to 100 ºC), and HF for hydrofluoric acid resistance. The flat tip shape, double-junction reference cell, and polymer electrolyte ensure superior measurement stability and long service life, even in chemically aggressive or high-temperature environments. The direct wire connection and digital RS485 output make the probe ideal for modern process control systems, immune to typical electrical interferences.
- Integrated PT100 temperature sensor enhances temperature compensation and accuracy.
- PVDF (polyvinylidene fluoride) construction ensures chemical resistance and durability.
- Ceramic reference junction for reliable operation in demanding media.
- 3/4” NPT threaded mount allows easy insertion or submersion in process lines.
- Double-junction reference protects against contamination and prolongs probe life.
- Wide pH measurement ranges: LT (0–12), HT (0–14), HF (0–10).
- Digital RS485 signal output for stable and remote monitoring.
- Operating pressure up to 6 bar and temperature up to 100 °C.
- 22.5 mm outer diameter for compatibility with standard process probe holders.
- Flat measuring tip and polymer electrolyte for high industrial performance.
This pH probe is perfectly suited for continuous pH monitoring in industrial, laboratory, chemical processing, and water treatment settings. For consistent results in harsh or high-interference environments, the HI1016-3850 Probe is an optimal choice.
Explore more process sensors and automation solutions in the "Probes & Sensors" category on EnvMart.
