Hanna Instruments HI8711 pH Analog Controller Dual Output, Self-Diagnostic, Fail Safe Alarm | EnvMart

Free Delivery in India | Lowest Global Shipping Charges

Hanna pH Analog Controller with Dual Output and Self-Diagnostic Test – HI8711

Name: Hanna pH Analog Controller with Dual Output and Self-Diagnostic Test – HI8711
Brand: Hanna
SKU: 71419
Price: 856.62 USD
Availability: InStock



Category pH Controllers Brand Hanna Condition New

Specifications

Country of Origin	India
Brand	HANNA Instruments
Power Supply	115 or 230 Vac, 50/60 Hz
Dimensions	141 x 69 mm
pH Range	0.00 to 14.00 pH
pH Resolution	0.01 pH
pH Accuracy	±0.02 (0 to 100 °C), ±0.05 (-20 to 0 °C) (electrode); ±0.5% (transmitter) pH
Environment	-10 to 50 °C, RH max 95% non-condensing
Model	HI8711
Enclosure	Black anodized aluminium body, ABS splash-proof front cover
Weight	1 kg
Voltage Output	±5 Vcc
Product Condition	New
MPN	HI8711
Analog Input Signal	4 to 20 mA
Analog Output Signal	0-20 mA or 4-20 mA (isolated)
Over Dosing Control	Adjustable, from 5 min to 60 min with knob or disable by wire strap
Max Load for Amplified Electrodes	150 mA
Dosing Control	OFF/AUTO/ON with selection switch
pH Dosing Relay	2, isolated, 2 A, Max 240 V, resistive load, 1000000 strokes
pH Alarm Tolerance Range	0.2 to 3.00 pH

Key Features

Hanna Instruments HI8711 pH Analog Controller is designed for precision industrial pH monitoring and dosing with dual output and advanced self-diagnostic features.

Features dual independent outputs for acid and alkaline dosage control.
Equipped with auto-diagnostics to verify offset, slope calibration, and electrode condition.
Incorporates Hanna’s exclusive Fail Safe Alarm System for reliable operation in industrial environments.
Selectable manual ON, OFF, and automatic dosing control modes with indicator.
Offers a 0.2 to 3.00 pH alarm tolerance range for accurate alerting.
Supports overtime dosing protection with adjustable settings from 5 to 60 minutes.
Compatible with both 115V and 230V power supplies at 50/60 Hz.
High-accuracy measurement of ±0.02 pH in operational temperature range (0-100°C).
Durable enclosure with black anodized aluminium body and ABS splash-proof front cover.
Dimensions: 141 x 69 mm for versatile panel or wall installation.

Product Description

Hanna Instruments HI8711 pH Analog Controller offers robust monitoring and dosing solutions for demanding industrial and laboratory applications. This controller is equipped for simultaneous acid and alkaline dosing via its dual isolated relay outputs. With setpoints adjustable throughout the full pH range (0.00 to 14.00), it enables precise dosing in processes that require tight pH control.

Auto-diagnostic features continuously verify offset, slope calibration, and electrode contamination, ensuring reliable operation and minimizing downtime. Hanna’s Fail Safe Alarm System provides protection against power supply failure or signal interruptions, automatically alarming with a red LED indicator on the front panel.

Dual output relays for independent acid and alkaline dosing control.
Selectable dosing operations: manual ON/OFF or automatic control with clear indication.
0.2 to 3.00 pH alarm tolerance adjustable for customized process safety.
Auto-diagnostics support offset, slope, electrode deterioration checks for electrode health.
Overtime dosing protection adjustable from 5–60 minutes, or can be disabled.
Continuous backlight display and splash-proof enclosure for harsh environments.
Compatible with both 115V and 230V AC power supplies, 50/60 Hz.
Panel dimensions: 141 x 69 mm, body made of black anodized aluminium with ABS splash cover.

Applications include process control, industrial water treatment, chemical dosing systems, and laboratory automation. Set suitability for commercial, manufacturing, pharmaceutical, and environmental monitoring. The package includes the HI8711 controller unit. Explore more controllers and laboratory monitoring instruments from Hanna Instruments and other leading brands in the EnvMart catalog.

Hanna pH Analog Controller with Dual Output and Self-Diagnostic Test – HI8711

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

Frequently Asked Questions

The Hanna Instruments HI8711 pH Analog Controller has a pH alarm tolerance range of 0.2 to 3.00 pH, allowing for precise monitoring and control.

The Fail Safe Alarm System alerts you with a red LED indicator in case of power supply failure or signal interruptions, ensuring reliable operation in industrial environments.

Yes, the HI8711 features dual independent outputs that allow for simultaneous acid and alkaline dosing control, making it versatile for various applications.

The HI8711 is compatible with both 115V and 230V AC power supplies at 50/60 Hz, providing flexibility for different operational environments.

The auto-diagnostic feature continuously checks the offset, slope calibration, and electrode condition to ensure accurate measurements and minimize downtime.

The HI8711 offers high-accuracy measurements of ±0.02 pH within its operational temperature range of 0-100°C.

Yes, the HI8711 features a durable enclosure made of black anodized aluminum and an ABS splash-proof front cover, making it suitable for harsh industrial environments.

The dimensions of the HI8711 are 141 x 69 mm, allowing for versatile installation options on panels or walls.

Yes, the HI8711 allows you to adjust the overtime dosing protection settings from 5 to 60 minutes, or you can disable it if not needed.

The HI8711 is ideal for applications in process control, industrial water treatment, chemical dosing systems, and laboratory automation.
