Labtron LIFM-B10 Inverted Fluorescence Microscope
Specifications
| Country of Origin | UK |
|---|---|
| Brand | Labtron |
| Model | LIFM-B10 |
| Optical System | NIS60 Infinite optical system |
| Type of Product | Microscope |
| Condenser | Motorized long working distance condenser / NA 0.55 / WD 26mm / with 6-position plate |
| Focusing | Motorized auto-focus / independent left/right hand wheels / three-speed adjustment / focusing range 9mm / repeat positioning accuracy — 0.1μm / motorized escape and recovery |
| Eyepiece | SW10X/25mm / Ø30mm |
| Viewing Head | Trinocular head with Bertrand lens / inclined at 45° / Interpupillary 47-78mm / 3-position beam split ratio — 50/50 / 100/0 / 0/100 |
| Nosepiece | Motorized 6-hole nosepiece with DIC slot (for transmitted and reflected) |
| Fluorescent attachment | Epi-fluorescence with 5W LED lamp / B/G/UV filters (100V-240V) / field diaphragm / center adjustable |
| Stage | Motorized three-layer mechanical stage / size — 340×230mm / movement range — 130(X)×100(Y)mm / flexible knob / attachable small stages |
| Transmitted Illumination | 5W LED illumination (service life — minimum 50 /000 hours) |
| C-mount Adapter | 1x C-mount Adapter |
| Internal Magnification | 1x / 1.5x |
| Side Video Port | Switchable by turning plate / 3 modes — Left side port/eyepiece equal to 50/50 / Right side port/eyepiece equal to 20/80 / Left & right side port/eyepiece equal to 0/100 |
| Motorized Filter Block | Multi-model / 6 positions / removable from the main frame for easy cube replacement |
Key Features
- Motorized condenser adjustment
- Trinocular head with Bertrand lens
- Long working distance condenser
- Epi-fluorescence LED illumination
- Motorized three-layer stage
- Multiple magnification settings
- Independent focus control
- Switchable side video port
- Removable filter cube design
Product Description
Inverted Fluorescence Microscope LIFM-B10 includes a motorized autofocusing mechanism with 0.1μm repeat positioning accuracy for clear imaging. It provides a magnification range of 100× to 400×, ensuring detailed fluorescence observation. The NIS60 infinite optical system enhances clarity and resolution for accurate analysis. A motorized 6-hole nosepiece with a DIC slot allows transmitted and reflected DIC imaging. Designed for fluorescence imaging, phase contrast studies, and live cell analysis in research laboratories.
Applications:
Our Inverted Fluorescence Microscope LIFM-B10 is ideal for observing cells and microorganisms, supporting continuous monitoring and capturing images for cytology, immunology, and genetic research.
Objective:Infinite Plan semi-APO phase contrast objective — 10x NA equal to 0.3 / WD equal to 8.1mm / Cover glass equal to 1.2mm / 20x NA equal to 0.45 / WD equal to 7.5 to 8.8mm / Cover glass equal to 0 to 2mm / 40x NA equal to 0.60 / WD equal to 3 to 4mm / Cover glass equal to 0 to 2mm
