Labtron LIBM-A20 Inverted Biological Microscope
Specifications
| Country of Origin | UK |
|---|---|
| Brand | Labtron |
| Dimension | 650 x 430 x 610 mm |
| Model | LIBM-A20 |
| Optical System | Infinite Optical System |
| Gross Weight | 14 Kg |
| Type of Product | Microscope |
| Filter | Blue / green / ground glass with diameter 45 mm |
| Condenser | Extreme long work distance condenser (ELWD) N.A. 0.3 / LWD 72 mm (without condenser 150 mm) |
| Illumination | 6V/30W halogen lamp / brightness adjustable |
| Eyepiece | High-point / Extra wide field eyepiece EW10X/22 mm |
| Viewing Head | Trinocular head inclined at 30° / interpupillary distance 48 to 75 mm |
| Nosepiece | Backward quintuple nosepiece |
| Focusing System | Coaxial Coarse & Fine adjustment / vertical objective movement / coarse stroke 37.7 mm per rotation / fine stroke 0.2 mm per rotation |
| Stage Dimensions | Plain stage — 160x250 mm / Glass insert / Auxiliary Stage — 70x180 mm |
| Centering Telescope Eyepiece | 30 mm |
| Phase Contrast Kit | 10X / 20X / 40X phase annulus plate |
Key Features
- Trinocular head design
- Infinite optical system
- 10X to 20X, 40X phase annulus plate
- Innovative stand structure
- 72 mm Extreme long working distance condenser
- Blue, Green & ground glass filters with 45 mm diameter
Product Description
Inverted Biological Microscope LIBM-A20 comes with a unique supporting stand structure and advanced optical functions. Equipped with a phase annulus plate, long working distance infinite plan and phase objectives, users can view high-resolution images of the cells, tissue, and other biological specimens. It is widely used in tissue culture and other life science industries for research and quality purposes.
Applications:
Used for applications in animal and plant tissue culture laboratories, fish laboratories, plant laboratories, and poultry laboratories.
Optional Accessories:
- Attachable Mechanical Stage, X-Y Coaxial Control, Moving Range 120×78 mm
- LWD Infinite Plan Objective: 10X/0.25, WD 10 mm
- LWD Infinite Plan Objective: 20X/0.4, WD 5.1 mm
- Infinite Plan Phase Objective: 40X/0.65, WD 0.35 mm
- Centering Telescope 30 mm
- Terasaki Holder, 38 mm Petri Dish Holder & 54 mm Slide Glass Holder
- 10X to 20X, 40X Phase Annulus Plate
- Photo Attachment
- Video Adapter with C Mount
Objectives:Long working distance (LWD) infinite plan objective — 4X/0.1 / WD 18 mm / Long working distance (LWD) infinite plan objective — 40X/0.6 / WD 2.6 mm / Infinite plan phase objective — PH10X/0.25 / WD 10 mm / Infinite plan phase objective — PH20X/0.4 / WD 5.1 mm
