Ruland Flexible Coupler Aluminium Clamp Style 12 mm Bore 25 mm OD 38.1 mm Length FCMR25-12-12-A

Free Delivery in India | Lowest Global Shipping Charges

Ruland Flexible Coupler Aluminium Clamp Style 12 mm Bore 25 mm OD 38.1 mm Length FCMR25-12-12-A

Name: Ruland Flexible Coupler Aluminium Clamp Style 12 mm Bore 25 mm OD 38.1 mm Length FCMR25-12-12-A
Brand: Ruland
SKU: 426258
Price: 85.28 USD
Availability: InStock



Category Mechanical Power Transmission Coupler Brand Ruland Condition New

Specifications

Country of Origin	our Marlborough
Screw Size	M4
Brand	Ruland
Length	38.1mm
Model	FCMR25-12-12-A
Maximum Speed	6000rpm
Maximum Operating Temperature	107°C
Minimum Operating Temperature	-40°C
Torque Rating	2.82Nm
Standards/Approvals	REACH, DIN 912 12.9, RoHS3
Hub Material	Aluminium
Moment of Inertia	4.12 x 10-6 kg/m²
Misalignment - Angular	3°
Misalignment - Parallel	0.38mm
Misalignment - Axial	0.25mm
Bellows Material	7075-T651 Extruded Drawn Aluminium Bar
Bore Size B	12mm

Key Features

Constructed from lightweight 7075-T651 extruded drawn aluminium bar providing high strength.
Clamp style design enables secure attachment and easy installation.
Capable of handling up to 2.82 Nm torque with a maximum speed of 6000 RPM.
Accommodates misalignments with 3° angular, 0.38 mm parallel, and 0.25 mm axial tolerances.
Operates within a temperature range of -40°C to 107°C for versatile industrial use.
Includes M4 sized screws compliant with DIN 912 12.9 standard and RoHS3 and REACH approvals.
Low moment of inertia at 4.12 x 10-6 kg/m² ensures reduced vibration and balanced performance.

Product Description

Ruland FCMR25-12-12-A flexible coupler is designed for precise mechanical power transmission where high reliability and reduced backlash are essential. Machined from a single piece of lightweight 7075-T651 extruded drawn aluminium bar, this clamp style coupler features a 12 mm bore on both sides, 25 mm outside diameter, and a length of 38.1 mm. Its robust construction allows it to withstand torque up to 2.82 Nm and operate at speeds up to 6000 RPM while effectively compensating for angular, parallel, and axial misalignments.

This coupler is ideal for applications including servo motor to lead screw connections, light-duty power transmission, and situations demanding precision alignment and vibration reduction. The inclusion of M4 screws adhering to DIN 912 12.9 and RoHS3 compliance ensures high holding power, anti-vibration performance, and environmental safety. Its operating temperature range from -40°C to 107°C supports deployment in varied industrial, manufacturing, and automation environments.

Lightweight aluminium hub reduces moment of inertia and facilitates smooth rotation. Clamp style design guarantees a secure and adjustable connection. Balanced design minimizes vibration for high-speed applications up to 6000 RPM.

Suitable for mechanical, laboratory, HVAC, and manufacturing uses requiring flexible couplings. Compliant with REACH and RoHS3 for regulatory adherence. M4 metric screws with Nypatch anti-vibration hardware maintain consistent screw installation torque and prevent galling.

Manufactured under strict controls to ensure quality and performance reliability.

Ruland couplers are trusted components in power transmission systems, enabling efficient torque transfer and alignment compensation in industrial machinery. This flexible coupler from the FCMR25 series delivers precision engineering for demanding mechanical applications. Browse more reliable flexible couplers and power transmission components in EnvMart’s comprehensive industrial supplies category.
