STMicroelectronics High Speed Surface Mount Comparator Push Pull Output 5V 2.2V 5-Pin SC-70 TS3011ICT

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics High Speed Surface Mount Comparator Push Pull Output 5V 2.2V 5-Pin SC-70 TS3011ICT

Name: STMicroelectronics High Speed Surface Mount Comparator Push Pull Output 5V 2.2V 5-Pin SC-70 TS3011ICT
Brand: STMicroelectronics
SKU: 425727
Price: 3.24 USD
Availability: InStock



Category Comparator Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1mm
Length	2.2mm
Model	TS3011ICT
Width	1.35mm
Mount Type	Surface
Output type	Push Pull
Series	TS3011
Maximum Operating Temperature	125°C
Package Type	SC-70
Minimum Operating Temperature	-40°C
Number Of Channels	1
Comparator Type	High Speed
Pin Count	5
Maximum Supply Voltage	5V
Minimum Supply Voltage	2.2V
Supply Current	900μA
Typical Response Time	8ns

Key Features

High Speed comparator with typical response time of 8 nanoseconds.
Surface mount package type SC-70, compact size with 2.2mm length and 1.35mm width.
Push pull output type for improved signal integrity.
Operates within temperature range -40°C to 125°C suitable for industrial applications.
Supply current approximately 900 microamperes ensuring low power consumption.
Single channel comparator ideal for precision electronic circuits.
Works with a minimum supply voltage of 2.2 volts and maximum of 5 volts.
Pin count of 5 supports integration in compact electronic designs.

Product Description

STMicroelectronics TS3011ICT is a high speed comparator designed for surface mount applications in compact SC-70 packages. This device operates with supply voltages ranging from 2.2 volts to 5 volts, enabling it to be used in low voltage electronic circuits. Featuring a push pull output, the TS3011ICT comparator provides clean signal transitions essential for high precision analog and digital interfacing.

With a typical response time of 8 nanoseconds, it is well suited for high frequency and fast switching applications in industrial, electronic manufacturing, and embedded systems. The single-channel configuration allows easy integration on printed circuit boards where space is critical.

The STMicroelectronics comparator is specified to operate over a wide temperature range from -40 to 125 degrees Celsius, ensuring reliable function in demanding environments including industrial controls and automotive electronics (non-AEC certified). The surface mount SC-70 package offers minimal footprint with dimensions of 2.2 mm length, 1.35 mm width, and 1 mm height, supporting modern compact electronic design trends.

The supply current is approximately 900 microamperes, making it a low power option for battery powered or energy conscious devices. With 5 pins for power, input, output, and ground connections, the TS3011ICT allows straightforward PCB integration with minimal routing complexity.

High speed response suitable for fast analog signal detection and switching. Compact SC-70 package for surface mount technology applications. Wide operating temperature range for industrial use cases. Low operating current minimizes power consumption in circuits.

Push pull output provides clean and strong drive capabilities. Single channel facilitates simple circuit integration. Low voltage operation down to 2.2 volts meets modern design needs. Mechanical dimensions support tight PCB layouts.

This comparator is commonly used in electronic components assemblies, semiconductor applications, amplifiers and comparators modules across electronics manufacturing, industrial instrumentation, and measurement systems.
