Sauter Compact Force Gauge 1000 Hz Sampling Rate 0.1 N Resolution 500N Capacity FC 500

Sauter FC 500 Force Gauge is a compact and robust force measuring device designed for accurate and reliable measurements in industrial, laboratory, manufacturing, and quality control applications. It provides a maximum measuring capacity of 500 Newtons with an exceptional resolution of 0.1 N and a high sampling rate of 1000 Hz.

The device features a turnable backlit display for versatile viewing angles and enhanced readability even in low-light conditions. It includes an internal memory that can store up to 1000 measurement values, enabling efficient data tracking and analysis.

This force gauge supports multiple measurement units such as ounces, Newtons, pounds, and kilograms, offering flexibility for various testing protocols. The metal housing provides durability and protection to withstand harsh environmental conditions common in industrial settings.

Connectivity is enhanced with standard USB and RS-232 data interfaces, allowing seamless data transfer to computers or other systems for further processing. The device operates on mains power and has a battery life of up to 20 hours for portable usage without interruption. A visual alarm feature helps alert operators when preset conditions are met during operation.

With operating temperature limits from -10°C to 40°C, it is suitable for a wide range of environments. The compact dimensions of 135mm length, 73mm width, and 34mm height make it suitable for handheld use and integration into testing setups.

Accuracy of 0.3 percent for dependable results. Resolution of 0.1 N with 1000 Hz sampling rate for capturing transient forces. Turnable and backlit display for user convenience. Internal memory for up to 1000 measurements.

Metal housing for robust durability. USB and RS-232 interfaces for data communication. Visual alarm to notify measurement events. Battery life up to 20 hours with mains power option. Operating temperature range: -10°C to 40°C.

Compact size: 135mm x 73mm x 34mm.

The Sauter FC 500 is ideal for diverse industrial and laboratory applications including force testing, quality control, material testing, assembly process verification, and research and development environments. This Force Gauge balances portability, precision, and durability to meet professional demands.
