RS PRO PCB Signal Relay 24V dc Coil 3A 4PDT 193-5850

Free Delivery in India | Lowest Global Shipping Charges

RS PRO PCB Signal Relay 24V dc Coil 3A 4PDT 193-5850

Name: RS PRO PCB Signal Relay 24V dc Coil 3A 4PDT 193-5850
Brand: RS PRO
SKU: 421746
Price: 94.07 USD
Availability: InStock



Category Signal Relay Brand RS PRO Condition New

Specifications

Country of Origin	United Kingdom
Brand	RS PRO
Height	9.9mm
Length	15mm
Model	193-5850
Width	9.9mm
Mount Type	PCB
Contact Material	Gold Plated
Series	RS PRO
Maximum Operating Temperature	70°C
Contact Configuration	4PDT
Minimum Operating Temperature	-40°C
Switching Current	3A
Terminal type	Solder
Contact Resistance	100mΩ
Standards/Approvals	RoHS
Coil Resistance	720Ω
Coil Voltage	24V dc
Switching DC Voltage	220V dc
Switching AC Voltage	250V ac
Coil Power	200mW

Key Features

This relay operates with a 24V DC coil voltage ensuring efficient power consumption.
Supports switching currents up to 3 amps suitable for signal-level applications.
Features a 4PDT (Four Pole Double Throw) contact configuration for versatile circuit control.
Designed for PCB mount with solder terminal type for secure connections.
Gold plated contacts reduce contact resistance and enhance durability and reliability.
Suitable for operation in a temperature range of -40°C to 70°C providing reliable performance in diverse environments.
Complies with RoHS standards ensuring environmental safety and quality assurance.
Compact dimensions of 15mm length, and 9.9mm width and height, suitable for dense PCB layouts.

Product Description

RS PRO 193-5850 is a high-quality PCB signal relay incorporating a 24V DC coil and a 3A switching current with a 4PDT contact configuration designed specifically for signal relay applications in electronic circuits.

This relay provides a drop-in replacement for obsolete models like Tyco/Axicom MT4 and Siemens V23104, equipped with polarised signal relays. The polarity selector switch offers versatile integration, ensuring compatibility with a wide range of signal relay circuits.

The relay’s gold-plated contacts minimize contact resistance to 100 mΩ, enhancing the reliability and longevity of signal transmission. It supports both AC switching voltages up to 250V and DC switching voltages up to 220V, making it suitable for various low voltage industrial control applications.

Its compact design with dimensions 15mm x 9.9mm x 9.9mm allows for efficient PCB mounting using solder terminals. Operating temperature spans from -40°C to 70°C, allowing it to perform reliably in harsh industrial or laboratory environments.

RS PRO 193-5850 adheres to RoHS environmental standards ensuring responsible manufacturing and reduced hazardous substances. Operates with 24V DC coil voltage for low power consumption. 3A switching current capacity suitable for signal conditioning.

4PDT contact configuration provides multi-pole switching in applications. Gold plated contact materials ensure minimal resistance and durability. Compact PCB mount relay designed for dense circuit boards. Wide operating temperature range of -40°C to 70°C for industrial use.

Compliance with RoHS for environmental safety. Low coil power consumption at 200mW with 720Ω resistance. Manufactured in the United Kingdom ensuring quality and reliability.

This relay is ideal for applications in electronics automation, signal conditioning, control systems, instrumentation, and electronic manufacturing where PCB-mounted signal relays are required.

Explore the RS PRO range and other Signal Relays at EnvMart for high-quality, reliable industrial components that meet strict performance standards.
