Molex Right Angle Surface Mount Female 1 Port USB Type B Connector USB 2.0 105164-0001

Free Delivery in India | Lowest Global Shipping Charges

Molex Right Angle Surface Mount Female 1 Port USB Type B Connector USB 2.0 105164-0001

Name: Molex Right Angle Surface Mount Female 1 Port USB Type B Connector USB 2.0 105164-0001
Brand: Molex
SKU: 420669
Price: 1.07 USD
Availability: InStock



Category USB Connector Brand Molex Condition New

Specifications

Country of Origin	China
Voltage	30V
Brand	Molex
Orientation	Right Angle
Current	1.8A
Mount Type	Surface
Contact Material	Copper Alloy
Series	1051
Number Of Ports	1
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-30°C
USB Type	USB Type B
Connector Gender	Female
USB Specification	USB 2.0

Key Features

USB 2.0 specification supporting data transfer rates and backward compatibility.
Right angle orientation for optimized PCB space and cable routing.
Single port USB Type B female connector designed for surface mount applications.
Solder termination type with copper alloy contact material ensures strong electrical connections.
Operates safely from -30°C to 85°C for diverse environmental conditions.
Supports a maximum current of 1.8A and a voltage rating of 30V.
Lead-free construction compliant with industry standards.
Micro-USB B receptacle without flange enables top mount installation.

Product Description

Molex 105164-0001 is a right angle, surface mount USB Type B female connector designed to meet USB 2.0 specifications, providing robust and reliable connections for various electronic devices.

This single port connector is ideal for printed circuit board (PCB) applications requiring compact and space-efficient solutions. Its right angle orientation supports effective cable management and reduced PCB footprint.

The connector features solder termination and uses copper alloy contact material to ensure durable and consistent electrical contact. It is lead-free, supporting environmentally safe manufacturing practices.

Engineered to operate within a wide temperature range from -30°C to 85°C, this connector is suitable for use in diverse industrial, consumer electronics, and commercial environments.

The product supports a current rating of 1.8 amperes and a voltage rating of 30 volts, making it appropriate for USB power and data transfer requirements. USB 2.0 compliance with backward compatibility. Right angle orientation for optimized PCB layout.

Single port USB Type B female connector for surface mount applications. Solder termination with copper alloy contacts for reliable connectivity. Operating temperature range of -30°C to 85°C for diverse usage conditions. Lead-free construction supporting RoHS compliance.

Current rating of 1.8A and voltage rating of 30V. Micro-USB B receptacle without flange, top mount design.

This USB connector is suitable for a wide array of applications, including industrial equipment, computer peripherals, communications devices, and consumer electronics requiring USB interfacing.
