RS PRO Electrical Linear Actuator 102 mm Stroke 4500N Load 24V DC Motor IP54 16.8mm/s Speed 177-4504

RS PRO 177-4504 Electrical Linear Actuator is a high-performance device designed for precise linear motion applications. Operating at 24V DC with a robust 4500N maximum load capacity, this actuator is ideal for various industrial, manufacturing, and automation systems requiring dependable straight-line actuation.

With a stroke length of 102 mm and a spindle pitch of 5.08 mm, it provides accurate and smooth movement along a linear path. The actuator utilizes an efficient DC motor technology, delivering speeds up to 16.8 mm/s under no load, making it suitable for rapid and repetitive tasks.

The IP54 rated housing protects internal components against dust and water splashes, enhancing durability and suitability for harsh industrial environments. Its operational temperature range from -20°C to 65°C allows for use in a wide variety of settings, from cold conditions to warm factory floors.

Compact with an overall length of 330 mm when closed, it is designed for installations where space is limited, such as windows, adjustable seats, or automotive driver adjustments. Additionally, the actuator includes built-in limit switches to prevent motor damage by cutting power at maximum stroke limits, ensuring longevity and reduced maintenance.

This model complies with EN 55014-1 and EN 55014-2 electromagnetic compatibility standards, reinforcing its reliability and safety in industrial systems. Weighing about 4.2 kg, it balances strength and manageable weight for ease of installation and replacement.

Application areas include machine tools, home and industrial automation, solar tracking systems, office automation, and other environments where precise, quiet, and powerful linear motion is required. Manufactured in Taiwan, Province Of China, RS PRO guarantees quality production and performance standards.

This actuator provides a maximum force of 4500N for robust push and pull operations. The stroke length is 102 mm, suitable for precise linear movement in limited spaces. Equipped with a DC motor technology ensuring efficient electrical power conversion.

Features an IP54 rating for protection against dust ingress and water splashes. Maximum speed reaches up to 16.8 mm/s without load for rapid actuation. Overall closed length measures 330 mm for compact installation. Operating temperature range spans from -20°C to 65°C for versatile environment tolerance.

Spindle pitch is 5.08 mm, ensuring fine and reliable control of movement. Compliant with EN 55014-1 and EN 55014-2 standards for electromagnetic compatibility. Weight is approximately 4.2 kg, balancing durability and manageability.

Manufactured in Taiwan, Province Of China, ensuring quality industrial standards. Discover the full range of RS PRO Electrical Linear Actuators and industrial mechanical products with EnvMart to enhance your automation and mechanical systems.
