KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD1-45M
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 18mm |
| Model | OHD1-45M |
| Depth | 5.6mm |
| Width | 5.5mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | OHD1 |
| Maximum Switching Current | 300mA |
| Maximum Operating Temperature | 150°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Wire |
| Contact Resistance | 150mΩ |
| Maximum Switching Power | 6W |
| Standards/Approvals | RoHS |
| Maximum Switching Voltage | 110V ac/dc |
Key Features
- Compact through hole mount design with wire terminals for easy integration.
- Nickel iron alloy contact material ensuring low contact resistance of 150 milliohms.
- Wide temperature operating range from -20°C to 150°C for harsh environments.
- High switching power capacity of 6 watts supporting varied signal strengths.
- Robust construction maintaining long operational life and environmental durability.
- Compatible for switching both AC and DC currents up to specified ratings.
- RoHS compliant adhering to environmental standards.
Product Description
KEMET OHD1-45M is a Single Pole Single Throw (SPST) through hole reed switch rated for a maximum switching current of 300 mA and a maximum switching voltage of 110 V (ac/dc). It features a nickel iron alloy contact material that ensures a contact resistance of approximately 150 milliohms, making it suitable for low power signal switching and control applications.
The switch is designed with wire-type terminals and a through hole mounting style for convenient PCB integration. It operates reliably within a temperature range of -20°C to 150°C, exhibiting excellent environmental durability including resistance to dust, corrosion, and explosion hazards. RoHS compliant, it meets current environmental and safety standards.
KEMET's OHD1 series reed switch incorporates advanced thermal guard technology for thermal problem countermeasures, ensuring high reliability for on/off operations and a long lifespan with high-speed response characteristics. The compact size, with dimensions measuring 18 mm in length, 5.5 mm in width, and 5.6 mm in depth, makes it highly adaptable to industrial, electrical, automation, and manufacturing uses.
Typical applications include atmospheric temperature sensing, overheating monitoring in power transistors, power modules, amplifiers, motors, and various general appliance control functions. It is dust, explosion, and corrosion proof, making it suitable for demanding industrial environments.
Compact through hole mount with wire terminals for PCB mounting. Nickel iron alloy contacts ensure low resistance and durability. Temperature operating range from -20°C to 150°C supports diverse environments. Supports maximum switching power of 6 W and current of 300 mA.
RoHS compliant meeting environmental safety standards. Advanced thermal guard technology for reliable switching operation. Robust construction resistant to dust, explosion, and corrosion. Applications include HVAC, power modules, motors, and industrial appliances.
Explore the range of Reed Switches at EnvMart for precision switching solutions across electrical and industrial sectors.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current of this model is 300 mA.
It operates reliably within a temperature range of -20°C to 150°C.
This unit features a Single Pole Single Throw (SPST) contact configuration.
The maximum switching voltage is 110 V for both AC and DC.
The contact resistance is approximately 150 milliohms.
The contacts are made from nickel iron alloy, ensuring low contact resistance and durability.
It features a through hole mounting style with wire terminals for easy PCB integration.
The maximum switching power supported by this model is 6 watts.
This unit measures 18 mm in length, 5.5 mm in width, and 5.6 mm in depth.
Yes, it is RoHS compliant, adhering to current environmental safety standards.
Typical applications include atmospheric temperature sensing, overheating monitoring in power transistors, and general appliance control functions.
It incorporates advanced thermal guard technology for reliable switching operations and high-speed response characteristics.
