KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD1-90M

Free Delivery in India | Lowest Global Shipping Charges

KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD1-90M

Name: KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD1-90M
Brand: KEMET
SKU: 417440
Price: 656.69 INR
Availability: InStock



Category Reed Switch Brand KEMET Condition New

Specifications

Country of Origin	Japan
Brand	KEMET
Length	18mm
Model	OHD1-90M
Depth	5.6mm
Width	5.5mm
Mount Type	Through Hole
Contact Material	Nickel Iron Alloy
Series	OHD1
Maximum Switching Current	300mA
Maximum Operating Temperature	150°C
Contact Configuration	SPST
Minimum Operating Temperature	-20°C
Terminal type	Wire
Contact Resistance	150mΩ
Maximum Switching Power	6W
Standards/Approvals	RoHS
Maximum Switching Voltage	110V ac/dc

Key Features

Single pole single throw (SPST) contact configuration.
Maximum switching current of 300 mA suitable for low-power control circuits.
Supports maximum switching power of 6 W for versatile applications.
Rated for maximum switching voltage of 110 V AC/DC providing operational flexibility.
Low contact resistance of 150 mΩ ensuring efficient electrical conduction.
Constructed with durable nickel iron alloy contacts for longevity.
Wire terminal type with through hole mount for easy PCB integration.
Wide operating temperature range from -20°C to 150°C for harsh environments.

Product Description

KEMET OHD1-90M SPST Through Hole Reed Switch is engineered for reliable switching operations with a maximum switching current of 300 mA and voltage up to 110 V AC/DC. The device features a nickel iron alloy contact material, ensuring long operational life and excellent environmental durability.

This reed switch uses a wire terminal and through hole mounting type, facilitating secure mounting on printed circuit boards. Its compact size with dimensions 18 mm length, 5.5 mm width, and 5.6 mm depth allows integration in space-constrained applications while maintaining performance.

Operating over a broad temperature range from -20°C to 150°C, the switch is suited for demanding industrial and commercial environments including automation systems, power modules, and heating appliances. The OHD Thermal Guard series provides enhanced thermal stability and responsiveness thanks to its unique magnet and temperature-sensitive Thermorite® material design.

Key benefits include high reliability for on/off switching, compatibility with low signal levels (0.1 mW or lower), and robustness against dust, corrosion, and explosions. These factors make it ideal for applications such as atmospheric temperature detection, overheating monitoring of electronic components, motors, hard disk drives, and general appliance controls.

Single pole single throw (SPST) contact configuration. Maximum switching current of 300 mA. Maximum switching power of 6 W. Maximum switching voltage of 110 V AC/DC. Contact resistance rating of 150 mΩ. Nickel iron alloy contact material for durability.

Wire terminal type with through hole mount. Operating temperature range from -20°C to 150°C. Compact dimensions: 18 mm (L) x 5.5 mm (W) x 5.6 mm (D). RoHS compliant for environmental safety.

Manufactured in Japan, this reed switch combines advanced materials and thermal guard technology for enhanced reliability and operational life. It is suitable for use in electronics, automation, HVAC systems, manufacturing equipment, and other industrial applications.
