Eaton Non-Resettable Fast Acting Fuse Radial 1A 250V AC Plastic Body SR-5F-1A-BK
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V ac |
| Diameter | 8.5mm |
| Brand | Eaton |
| Body Material | Plastic |
| Height | 8.1mm |
| Length | 7.6mm |
| Model | SR-5F-1A-BK |
| Width | 8.5mm |
| Current Rating | 1A |
| Series | SR-5F |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Lead Length | 4.3mm |
| Breaking Capacity | 50A |
| Standards/Approvals | UL, RoHS, IEC 600680, MILSTD0F, UL 94V0, UL 4814 |
| Lead Diameter | 0.6mm |
| Fuse Characteristics | Fast Acting |
| Lead Orientation | Radial |
Key Features
- Fast-acting fuse with a current rating of 1 ampere.
- Operating voltage of 250 volts AC supports various electrical applications.
- Plastic thermoplastic polyamide body ensures durability and safety.
- Radial lead orientation with 4.3mm lead length and 0.6mm lead diameter.
- Breaking capacity of 50 amps protects circuits from overload damage.
- Wide operating temperature range from -40°C to 125°C.
- Complies with UL, RoHS, IEC 600680, MILSTD0F, UL 94V0, and UL 4814 standards.
Product Description
Eaton SR-5F-1A-BK is a non-resettable fast acting fuse with a radial lead orientation, rated for 1 ampere current and 250 volts AC. It features a robust plastic thermoplastic polyamide body designed for reliable circuit protection in electrical and automation systems.
This fuse provides fast acting protection with a breaking capacity of 50 amps, effectively safeguarding circuits against overcurrent conditions. Its compact dimensions - 7.6mm length, 8.5mm diameter and width, and 8.1mm height - make it suitable for PCB mounting and space-constrained applications.
The fuse operates reliably across a wide temperature range from -40°C minimum to 125°C maximum, making it suitable for diverse industrial and commercial environments. The radial lead orientation and 4.3mm lead length with 0.6mm diameter enable easy integration into circuit assemblies.
Manufactured to comply with strict standards including UL, RoHS, IEC 600680, MILSTD0F, UL 94V0, and UL 4814, this product ensures high safety and environmental compliance. Eaton, formerly known as Bussmann, designs the SR-5F series as subminiature fuses optimized for PCB fuse solutions across automation, electrical, and industrial applications.
Fast-acting fuse with a current rating of 1 ampere. Operating voltage of 250 volts AC supports various electrical applications. Plastic thermoplastic polyamide body ensures durability and safety. Compact dimensions: length 7.6mm, diameter 8.5mm, width 8.5mm, height 8.1mm.
Radial lead orientation with 4.3mm lead length and 0.6mm lead diameter. Breaking capacity of 50 amps protects circuits from overload damage. Wide operating temperature range from -40°C to 125°C. Complies with UL, RoHS, IEC 600680, MILSTD0F, UL 94V0, and UL 4814 standards.
This fuse is ideal for use in industrial automation, electrical equipment, manufacturing, and PCB protection applications that require dependable, non-resettable overcurrent protection.
Explore additional Eaton electrical and automation components on EnvMart for comprehensive project needs.
Explore more products in our Non-Resettable Fuse category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 1 ampere.
It operates at a maximum voltage of 250 volts AC.
The breaking capacity is 50 amps, which helps protect circuits from overload damage.
The fuse has a length of 7.6mm, a diameter of 8.5mm, and a height of 8.1mm.
It features a radial lead orientation with a lead length of 4.3mm and a lead diameter of 0.6mm.
The operating temperature range is from -40°C to 125°C.
The body is made from plastic thermoplastic polyamide, ensuring durability and safety.
It complies with UL, RoHS, IEC 600680, MILSTD0F, UL 94V0, and UL 4814 standards.
This model is suitable for industrial automation, electrical equipment, manufacturing, and PCB protection applications.
This fuse belongs to the SR-5F series.
The country of origin for this fuse is India.
It is a non-resettable fast acting fuse, designed for reliable circuit protection.
