LDK M12 Female 304 Stainless Steel Rod End, 12mm Bore Metric SPHS12EC x 1.25

The LDK SPHS12EC x 1.25 stainless steel rod end is engineered for demanding mechanical and industrial uses where precision and durability are essential. This rod end features an M12 female connection thread with a 12mm bore size, making it suitable for metric assembly systems and equipment requiring a high-quality rotary bearing solution.

The body is fabricated from robust 304 stainless steel, offering excellent corrosion resistance for use in challenging environments. The ball is constructed from heat-treated 440C stainless steel, precision ground and polished, with a Rockwell hardness (HRC) of at least 56, ensuring optimal wear resistance and long operational life.

The rod end includes a PTFE composite race and sliding contact surfaces composed of steel and PTFE materials, which reduce friction and provide smooth rotary motion under dynamic loads up to 13.5 kN and static loads up to 22.7 kN. With an outside diameter of 30mm and an overall width of 65mm, it provides compact yet sturdy performance.

This product is ideal for use in industrial machinery, fluid power systems, automotive assemblies, and other applications requiring precise rotary bearing solutions. It conforms to metric thread standards with a female connection gender, supporting easy integration.

Constructed of 304 stainless steel body for corrosion resistance and durability. Heat-treated precision 440C stainless steel ball for high wear resistance. PTFE composite race to lower friction and enhance service life. Dynamic load rating of 13.5 kN supports heavy-duty applications.

Static load rating of 22.7 kN ensures reliability under static conditions. 30mm outside diameter and 65mm overall width provide compact design. Smooth sliding surfaces of steel/PTFE composite reduce wear and improve motion.

Metric standard M12 female connection for compatibility with metric threads. Manufactured in China under strict quality standards.

This rod end is an essential component for industries such as manufacturing, construction, automotive, and fluid power, where robust and reliable rotary bearing solutions are critical. Explore the full range of LDK Rod Ends for additional sizes and configurations suitable for your technical requirements.
