Lumel Digital Panel Multifunction Meter LED Display Current Voltage Measurement N25-S250000E0
Specifications
| Country of Origin | Poland |
|---|---|
| Display Type | LED |
| Brand | Lumel |
| Dimensions | 96 x 48 x 64 mm |
| Model | N25-S250000E0 |
| Depth | 64mm |
| Series | N25 |
| Supply | 85…253 V a.c./d.c. or 20…24 V a.c./d.c., 110 V a.c., 230 V a.c |
| Maximum Operating Temperature | 55°C |
| Meter Type | Digital |
| Number Of Digits | 5 |
| Minimum Operating Temperature | -10°C |
| Digit height | 14mm |
| Standards/Approvals | CE Certified |
| Properties Measured | Current, Voltage |
| Minimum Measurement | -66 mV, -11 mV, -11 V, -1 mA, -0.5 V, 3.6 mA |
| automatic or manual compensation | temperature of cold junction for measurements with thermocouples or wire resistance for Pt100 sensors (N25T) |
Key Features
- Features a clear 5-digit LED display with 14 mm digit height.
- Measures d.c. and a.c. voltage and current with minimum measurements of -66 mV to 3.6 mA.
- Allows configuration via PD14 programmer and free LPConfig software.
- Includes automatic or manual compensation for temperature and sensor resistance.
- Supply voltage options range between 20 V to 253 V a.c./d.c. and 110 V or 230 V a.c.
- Operates safely between -10°C and 55°C ambient temperatures.
- Compact dimensions of 96 x 48 x 64 mm for easy panel integration.
Product Description
Lumel N25-S250000E0 Digital Panel Multifunction Meter is designed for accurate measurement of current and voltage in industrial and automation applications. It includes a bright 5-digit LED display with 14 mm high digits for easy readability.
This digital meter can measure various electrical properties such as d.c. voltage, d.c. current, temperature from Pt100 sensors, J and K thermocouples, a.c. voltage, and a.c. current. The device supports precise display formatting, including decimal point accuracy and measurement averaging.
Configuration of the meter's parameters is made possible through the PD14 programmer or the free LPConfig program, allowing customization tailored to specific application needs.
The meter accepts supply voltage from 85 to 253 V a.c./d.c. or 20 to 24 V a.c./d.c., including common industrial voltages such as 110 V and 230 V a.c. It is CE certified and built to operate in ambient temperatures between -10°C and 55°C, ensuring durability in varied industrial environments.
Measuring 96 mm in length, 48 mm in width, and 64 mm in depth, the compact form factor facilitates seamless installation into control panels and process control systems. Features a clear 5-digit LED display with 14 mm digit height.
Supports measurements of d.c. and a.c. voltage and current along with temperature sensing. Configurable parameters via PD14 programmer and LPConfig software. Includes automatic/manual compensation for thermocouple and sensor wire resistance.
Accepts a wide range of supply voltages from 20 V to 253 V a.c./d.c., including 110 V and 230 V. Robust operation from -10°C to 55°C ambient temperature. Compact dimensions of 96 x 48 x 64 mm for panel mounting.
This meter is ideal for industrial automation, electrical panel monitoring, process control, manufacturing systems, and laboratory instrumentation. Its advanced features provide precise electrical measurements essential for system performance and safety.
Explore more industrial automation and control products for enhanced operational efficiency on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can measure d.c. and a.c. voltage and current, with minimum measurements of -66 mV to 3.6 mA.
It accepts supply voltages ranging from 85 to 253 V a.c./d.c. or 20 to 24 V a.c./d.c., including common voltages of 110 V and 230 V a.c.
The meter operates safely between -10°C and 55°C ambient temperatures.
It features a clear LED display with 5 digits and a digit height of 14 mm for easy readability.
The dimensions of this unit are 96 mm in length, 48 mm in width, and 64 mm in depth, making it suitable for panel mounting.
It measures current, voltage, and temperature from Pt100 sensors, as well as J and K thermocouples.
Configuration can be done via the PD14 programmer or the free LPConfig software, allowing for customization to specific application needs.
Yes, it includes automatic or manual compensation for the temperature of the cold junction for thermocouple measurements and wire resistance for Pt100 sensors.
This model is CE certified, ensuring compliance with relevant safety and performance standards.
The maximum operating temperature for the Lumel N25-S250000E0 is 55°C.
It can measure minimum values of -66 mV, -11 mV, -11 V, -1 mA, -0.5 V, and 3.6 mA.
It is suitable for industrial automation, electrical panel monitoring, process control, manufacturing systems, and laboratory instrumentation.
