Weidmüller BL Series Pluggable Terminal Block 2-Contact 3.5 mm Pitch 1 Row 320V 17A 1615780000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Weidmüller |
| Colour | Black |
| Current | 17A |
| Length | 3.5mm |
| Depth | 18.5mm |
| Width | 13mm |
| Housing Material | Polybutylene Terephthalate |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 2 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.08mm² |
| Maximum Wire Size mm² | 2.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
Key Features
- Constructed with polybutylene terephthalate housing for durability.
- Supports wire sizes from 0.08 mm² (28 AWG) to 2.5 mm² (14 AWG).
- Features a screw connection method with a male connector gender.
- Black colour design suitable for various electronic applications.
- Clamping yoke screw system enables easy wiring and reliable connection.
- Current rating corresponds to rated cross-section and minimum number of poles.
- Designed with hardened and zinc-chromed plated steel for long-lasting conductivity.
- Compact single-row design saves PCB space in electronic assemblies.
Product Description
Weidmüller 1615780000 BL Series pluggable terminal block offers a technical solution for high-quality electrical connections in industrial and electronic systems. Rated at 320V and 17A current capacity, this 2-contact, 3.5 mm pitch terminal block features a single-row configuration optimized for compact PCB mounting.
The housing is crafted from polybutylene terephthalate, providing electrical insulation and mechanical robustness for demanding applications. The terminal block supports a wire cross-section range from 0.08 mm² to 2.5 mm², accommodating 28 AWG to 14 AWG wire gauges. Its screw connection method secures wires firmly while allowing simple installation or maintenance.
The male connector design integrates easily with mating harness connectors available in tension clamp or rising clamp screw terminals. The clamping yoke mechanism offers straightforward wiring with a straight outlet orientation, ensuring reliable electrical contact with hardened zinc-chromed steel components plated for corrosion resistance. The terminals utilize tin-plated copper alloy for optimal conductivity and durability.
Measuring 3.5 mm in length, 13 mm in width, and 18.5 mm in depth, this pluggable terminal block provides space-saving solutions in PCB applications. It aligns with the Weidmüller Omnimate range, known for cost-effective and efficient connector systems. The block is designed without specific standards approvals but built for industrial automation, manufacturing, and electronic control gear applications.
2-Contact pluggable terminal block for compact electronic connectors. Screw termination with clamping yoke for reliable wire connection. Housing material is high-quality polybutylene terephthalate. Wide wire size compatibility from 0.08 mm² to 2.5 mm².
Supports current rating up to 17A and voltage of 320V. Compact design with 3.5 mm pitch and 1 row layout. Durable zinc-chromed steel clamping yoke and tin-plated copper alloy terminals. Ideal for industrial, manufacturing, and automation electronics.
Manufactured in Germany ensuring high quality standards. Explore extensive product options and accessories within the Pluggable Terminal Blocks category on EnvMart for your industrial and electrical connection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block has a current rating of 17A and can handle a voltage of 320V.
It supports wire sizes ranging from 0.08 mm² (28 AWG) to 2.5 mm² (14 AWG).
The terminal block features a 3.5 mm pitch and has a single-row configuration.
The housing is made from polybutylene terephthalate, and it includes hardened zinc-chromed steel components for conductivity.
Wiring is connected using a screw connection method, which ensures a secure and reliable connection.
It measures 3.5 mm in length, 13 mm in width, and 18.5 mm in depth.
It is suitable for industrial automation, manufacturing, and electronic control gear applications.
This terminal block is built for industrial use but does not have specific standards approvals mentioned.
It includes a clamping yoke screw system that facilitates easy wiring and ensures reliable electrical contact.
It is manufactured in Germany, ensuring adherence to high quality standards.
Extensive product options and accessories can be explored within the Pluggable Terminal Blocks category on EnvMart.
