Eaton Non-Resettable Fuse Radial 1.6A 300V AC Plastic Body Time Delay SR-5H-1-6A-BK

Eaton SR-5H-1-6A-BK is a Non-Resettable Fuse designed for primary and secondary overcurrent protection in a wide range of industrial and electrical applications. Featuring a time delay attribute, it can withstand high inrush currents typically found in motor start-ups and transformer circuits without nuisance blowing. Its radial lead design and compact dimensions allow easy integration onto printed circuit boards.

The fuse body is constructed from a thermoplastic polyamide material providing robust insulation and durability, while the lead length and diameter are optimized for reliable soldering and mechanical stability. Operating temperatures range from -40°C up to 85°C, making it suitable for diverse environmental conditions.

The breaking capacity of 100A ensures safe disconnection under fault conditions, protecting sensitive components and equipment. Eaton's SR-5H series complies with important standards such as UL 94V0, RoHS, IEC 60068-2-20, and IEC 60127-3, guaranteeing product safety, environmental compliance, and performance reliability.

Manufactured in China, this fuse is an ideal solution for electrical, automation, and industrial sectors requiring reliable and compact circuit protection devices. The fuse has a plastic polyamide body providing durability and insulation.

It features time delay characteristics suitable for high inrush currents. Dimensions include length 8.7 mm, width 8.5 mm, height 9.2 mm, and diameter 8.5 mm for compact PCB mounting. Operating temperature ranges from -40°C minimum to a maximum of 85°C, supporting various environmental conditions.

Lead length is 4.3 mm with a diameter of 1 mm, arranged radially for PCB compatibility. Breaking capacity of 100A ensures safe disconnection under fault conditions. The fuse complies with standards UL 94V0, RoHS, IEC 60068-2-20, and IEC 60127-3 for safety and quality assurance.

Widely used in electrical, automation, and PCB protection applications. Explore more Eaton fuses and electrical protection devices in our Electronics & Electricals category on EnvMart for high-quality and trusted industrial components.
