Microchip MOSFET Gate Driver 2 Outputs 1.5 A 8-Pin SOIC 4.5-18V TC4426AEOA
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.42mm |
| Length | 4.9mm |
| Model | TC4426AEOA |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TC442 |
| Output Current | 1.5A |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Rise Time | 40ns |
| Standards/Approvals | ESD Protected 4 kV, ISO/TS-16949:2009 Certified (company) |
| Pin Count | 8 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 4.5V |
| Number of Drivers | 2 |
| Fall Time | 40ns |
| Driver Type | MOSFET |
| Standards/ApprovalsESD Protected 4 kV, ISO/TS-16949 | 2009 Certified (company) |
Key Features
- This MOSFET driver offers fast rise and fall times of 40 nanoseconds each.
- Operates reliably over a wide temperature range from -40°C to 85°C.
- Designed for surface mount applications with small form factor dimensions of 4.9 mm length, 3.91 mm width, and 1.42 mm height.
- Includes ESD protection up to 4 kV to enhance durability in harsh electrical environments.
- Comprises two independent driver outputs, ideal for driving MOSFET and IGBT switches with precision.
Product Description
Microchip TC4426AEOA is a dual MOSFET gate driver designed to provide high peak output current of 1.5 A. Packaged in a compact 8-pin SOIC casing, it supports supply voltages from 4.5 V up to 18 V and delivers fast switching performance with 40 ns rise and fall times. This driver operates efficiently across a broad temperature range from -40°C to 85°C, ensuring robustness in demanding industrial, automotive, and power management systems.
With its surface mount architecture and small overall footprint of 4.9 mm length, 3.91 mm width, and 1.42 mm height, the TC4426AEOA is ideal for PCB designs requiring compact power driver solutions. Its dual outputs allow concurrent driving of two MOSFETs or IGBTs, enhancing control flexibility in electronic circuits.
The device is ESD protected up to 4 kV, safeguarding it against electrostatic discharge damage during handling and operation. Additionally, it is ISO/TS-16949:2009 certified, reflecting Microchip’s commitment to quality standards relevant to automotive components. This makes the gate driver suitable for use in automotive electronics as well as in general power management applications involving MOSFET and IGBT switching devices.
This gate driver features dual outputs, enabling simultaneous control of two power transistors. Offers rapid switching with 40 ns rise and fall times for efficient power control. Supports wide voltage supply from 4.5 V to 18 V, suitable for various power architectures.
Designed for surface mount assembly with an 8-pin SOIC package for space-constrained designs. Operates reliably across an extended temperature range from -40°C to 85°C for industrial-grade performance. Incorporates comprehensive ESD protection up to 4 kV to improve device longevity.
Certified to ISO/TS-16949:2009 standards, making it suitable for automotive electronics.
This Microchip TC4426AEOA MOSFET gate driver is an essential component for industrial, automotive, electronic manufacturing, and power management systems requiring efficient and reliable MOSFET or IGBT driving capabilities. Explore related power management ICs and Gate Drivers on EnvMart to find compatible and complementary components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a peak output current of 1.5 A, suitable for driving MOSFETs and IGBTs effectively.
It operates reliably over a wide temperature range from -40°C to 85°C, making it suitable for various applications.
The dimensions of this unit are 4.9 mm in length, 3.91 mm in width, and 1.42 mm in height, designed for compact applications.
It features fast rise and fall times of 40 nanoseconds each, enabling efficient switching performance.
The TC4426AEOA supports a supply voltage range from 4.5 V to 18 V, accommodating various power architectures.
This MOSFET gate driver has two independent outputs, allowing for the concurrent driving of two MOSFETs or IGBTs.
It comes in an 8-pin SOIC package, suitable for surface mount applications.
This model is ISO/TS-16949:2009 certified, which reflects its adherence to quality standards relevant to automotive components.
It is suitable for use in industrial, automotive, electronic manufacturing, and power management systems requiring efficient MOSFET or IGBT driving capabilities.
This model is designed for surface mounting, making it ideal for space-constrained PCB designs.
