Littelfuse Non-Resettable Fuse 375mA 125V Ceramic Body Time Delay 0452.375MRL

Littelfuse 0452.375MRL non-resettable fuse is designed for precise and reliable circuit protection in low voltage applications. This fuse has a current rating of 375mA and a maximum voltage rating of 125V, suitable for protecting sensitive electronic components.

The fuse body is made of ceramic material providing excellent durability and thermal stability, ensuring performance under demanding environmental conditions. Its time delay characteristic allows it to withstand transient inrush currents without nuisance opening, enhancing component protection.

With gold plated terminals, this fuse offers superior electrical connectivity and corrosion resistance, making it ideal for use in critical electronics like alarm systems, audio/visual equipment, computer boards, and medical devices.

Compact dimensions of 2.69mm width, 2.69mm height, and 6.1mm depth allow for space-saving designs and surface mount technology implementation. The fuse can safely interrupt fault currents up to 50A, providing robust breaking capacity.

Operating temperature range from -55°C minimum to 125°C maximum ensures reliable operation across a wide spectrum of industrial and commercial applications. This fuse is supplied on a reel package type, enabling efficient integration into automated manufacturing processes and enhancing production efficiency.

It conforms to industry standards RoHS, UL 248-14, and CSA, guaranteeing compliance with regulatory and safety requirements. Constructed with a ceramic body for durability and heat resistance. Time delay fuse characteristics accommodate transient surge currents.

Gold plated terminals ensure excellent conductivity and corrosion resistance. Compact size with dimensions 2.69mm width, 2.69mm height, and 6.1mm depth. Breaking capacity rated at 50A for safe circuit interruption. Operating temperature range from -55°C to minimum 125°C for versatile conditions.

Package supplied on reel for efficient automated assembly. Meets standards including RoHS, UL 248-14 and CSA for quality assurance.

This Littelfuse Non-Resettable Fuse is suitable for applications in electronics manufacturing, industrial automation, HVAC systems, medical apparatus, and telecommunications. Its reliable protection and compact form factor support high-value and sensitive device safeguarding.
