TE Connectivity Miniature PCB Signal Relay 24V DC Coil, 1A Switching Current, DPDT Contact Configuration TSC-124L3H000
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 9mm |
| Length | 12.3mm |
| Model | TSC-124L3H000 |
| Width | 7.4mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | TSC |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -30°C |
| Switching Current | 1A |
| Terminal type | Solder |
| Contact Resistance | 50mΩ |
| Standards/Approvals | REACH, RoHS |
| Coil Resistance | 1900Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 125V ac |
| Coil Power | 300mW |
| Switching Power | 24W |
| TSC Series of miniature PCB relays. Typical applications include | Telecommunications, office machines and security systems |
| TE Connectivity PCB Signal Relay, 24V dc Coil, 2A, DPDTBrand | TE Connectivity |
Key Features
- This relay has a low coil power requirement of 300mW, suitable for IC compatibility.
- The contact material is gold plated to ensure reliable signal transmission.
- Designed for PCB mounting with solder type terminals for easy installation.
- It operates within a temperature range of -30°C to 80°C, suitable for diverse environments.
- The compact relay dimensions are 12.3mm length, 7.4mm width, and 9mm height.
- It switches at voltages up to 125V AC and 30V DC with a power rating of 24W.
- Sealed plastic case design provides durability and protection for industrial and electronic applications.
Product Description
TE Connectivity offers the TSC-124L3H000 miniaturized PCB signal relay, engineered with a 24V DC coil and a double-pole double-throw (DPDT) contact configuration. It supports a 1A switching current, making it ideal for reliable signal control in sensitive electronic circuits.
This relay features gold-plated contacts and a low coil power consumption of 300mW, which allows it to function efficiently with integrated circuits. The coil resistance is 1900Ω, ensuring stable operation.
The relay is designed for printed circuit board mounting with solder terminals, providing straightforward assembly. Its sealed plastic housing protects against environmental factors, enhancing longevity and reliability in telecommunications, office machinery, and security system applications.
Operating temperatures range from -30°C to 80°C, enabling use in various industrial and commercial environments. Its compact size, with dimensions of 12.3mm length, 7.4mm width, and 9mm height, ensures minimal space utilization.
Low coil power requirement of 300mW enhances compatibility with IC circuits. Gold-plated contacts ensure superior conductivity and reliability. Double-pole double-throw (DPDT) contact configuration for flexible switching options.
Suitable for telecommunications, office machines, and security systems. Sealed plastic case provides durability and protection from environmental factors. Compact dimensions facilitate integration into space-constrained assemblies.
This miniature signal relay is indispensable in electronics manufacturing, industrial automation, and other applications requiring reliable and low-power switching solutions. Its compliance with REACH and RoHS standards ensures it meets environmental safety requirements.
Explore similar Signal Relays and other TE Connectivity solutions at EnvMart for your industrial and commercial needs.
