Schneider Electric Residual Current Circuit Breaker with Overload Protection 32A 1-Pole 30mA Trip A9DX3632

Schneider Electric A9DX3632 Residual Current Circuit Breaker with Overload Protection is engineered to deliver superior circuit protection for residential and distribution electrical systems. It incorporates advanced thermal-magnetic trip unit technology combined with instantaneous earth-leakage protection for efficient overload, short-circuit, and leakage current interruption.

This 1-pole breaker operates at a current rating of 32 amperes with a sensitive trip value of 30 milliampere, ensuring quick response to earth faults. Mountable on standard DIN rails, its compact form factor measures 93mm in height, 36mm in width, and 73mm in depth, fitting most electrical distribution boards.

The toggle switch actuator offers clear ON/OFF and trip indication, facilitating easy operation and maintenance. Conforming to stringent EN/IEC 60947-2 and RoHS certifications, this device guarantees compliance with international quality and environmental standards.

It is rated for 400V AC with a breaking capacity of 10 kiloamperes, suitable for a broad range of electrical installations requiring high reliability and safety. The breaker features tunnel-type terminals for secure wiring connections and provides AC earth leakage protection type functionality.

Designed for durability, the breaker withstands impulse voltages up to 4 kV and supports electrical endurance of up to 20,000 operational cycles. It functions efficiently within an ambient temperature range of -5 to 60 °C and tolerates up to 95% relative humidity at 55 °C, making it adaptable to diverse environments.

Additional safety features include a padlockable design, preventing unauthorized operation and enhancing circuit safety. This product is part of Schneider Electric's renowned Acti9 series, distinguished by its premium green certification reflecting environmentally conscious manufacturing.

This Residual Current Circuit Breaker is ideal for industrial, residential, distribution, and commercial electrical protection applications, ensuring robust overload and fault protection. It is manufactured in France, ensuring adherence to the highest quality standards and reliability.

Explore the range of Schneider Electric circuit breakers and accessories on EnvMart to find compatible and high-performance solutions tailored to your electrical protection needs. The circuit breaker features thermal-magnetic tripping technology for overload and short circuit protection.

It is designed for DIN rail mounting with a toggle switch reset actuator. The breaker complies with EN/IEC 60947-2 and RoHS standards ensuring safety and environmental compliance. Compact size with dimensions of 93mm height, 36mm width, and 73mm depth.

Rated for 400V AC operation with a breaking capacity of 10kA suitable for residential and distribution applications. Provides AC earth leakage protection type with instantaneous earth leakage trip mechanism. Designed to withstand impulse voltage of 4 kV and electrical durability of 20,000 cycles.

Operates reliably within ambient temperatures of -5 to 60 °C with relative humidity tolerance up to 95% at 55 °C. Padlockable design offers additional safety and tamper resistance. Manufactured in France with high quality Schneider Green premium class certification.
