ABB Residual Current Circuit Breaker with Overload Protection, 10A Current Rating, 2-Pole, 30 2CSR255080R1105 DS201 B10 AC30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSR255080R1105 DS201 B10 AC30
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	10A
Series	DS201
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	2
Standards/Approvals	IEC, RoHS
Rated AC Voltage	230V ac
Tripping Characteristics	Type B
Tripping Mechanism	Thermal Magnetic
Trip Sensitivity	30mA
Earth Leakage Protection Type	AC

Key Features

Provides thermal magnetic tripping mechanism for overload and short circuit protection.
Designed for 230V AC rated voltage and 2 poles suitable for single-phase circuits.
Features DIN rail mount type and screw terminal connection for easy installation.
Has breaking capacity of 6kA ensuring robust disconnection performance.
Compact dimensions measuring 85mm height, 69mm depth, and 35mm width.
Equipped with type B tripping characteristics suitable for a range of applications.
Includes earth leakage protection type AC for sensitive fault current detection.
Conforms to IEC standards and RoHS compliance for safety and environmental requirements.

Product Description

ABB 2CSR255080R1105 DS201 B10 AC30 Residual Current Circuit Breaker with Overload Protection is engineered for effective overload and earth fault protection in single-phase AC electrical systems.

Operating at a rated voltage of 230V AC with a current rating of 10A and 2 poles, this breaker provides precise protection with 30mA trip sensitivity to quickly detect and disconnect fault currents.

The thermal magnetic tripping mechanism safeguards circuits against overload and short-circuit conditions, ensuring electrical safety and equipment protection.

This DS201 series device features a compact two-module width design with screw terminal type for secure wiring and a DIN rail mounting configuration for easy integration into distribution boards.

With a breaking capacity of 6kA and type B tripping characteristics, it is suitable for industrial, laboratory, HVAC, manufacturing, and commercial electrical applications requiring reliable earth leakage and overload protection.

Thermal magnetic tripping mechanism protects against overload and short circuits. Rated current 10A at 230V AC with 2-pole configuration. Trip sensitivity of 30mA for AC earth leakage protection. DIN rail mounting and screw type terminals for installation flexibility.

Compact dimensions of 85mm height, 69mm depth, and 35mm width save panel space. Breaking capacity 6kA supports robust fault clearing. Certified to IEC standards and RoHS compliant for safety and environmental compliance.

IP20 terminal and IP40 housing degree of protection for durability. Ideal for use in electrical automation, industrial plants, water treatment, commercial power systems, and manufacturing environments.

Set your electrical installations up with ABB’s quality Residual Current Circuit Breaker for reliable, precise, and safe protection against overloads and earth faults. Browse the Electronics & Electricals category on EnvMart for more circuit breakers and automation products.
