Schneider Electric TeSys GV4PE Thermal Circuit Breaker 3-Pole 115A 690V AC DIN Rail GV4PE115S

Schneider Electric GV4PE115S Thermal Circuit Breaker is a high-performance motor protection device designed under the TeSys GV series. It offers reliable thermal magnetic tripping mechanisms to safeguard 3-phase motors with a current rating of 115A, suitable for motor power ratings between 37 to 55 kW at 400V. This 3-pole circuit breaker is DIN Rail mountable and features robust screw terminal connections using Everlink BTR technology for secure wiring.

The breaker includes a toggle switch type reset actuator facilitating easy manual control for start-stop operations. Thermal protection is adjustable via dials with an Ir setting range from 65A to 115A and selectable tripping classes 10 or 20, ensuring precise motor protection tailored to application needs.

Enhanced motor protection features encompass fixed pick-up short time delay (Isd) at 13 times the rated current, phase unbalance protection, loss protection, and ground fault detection, making it suitable for demanding industrial environments.

Designed to comply with a broad spectrum of standards such as IEC, UL, CSA, CCC, EAC, ATEX and compliant with RoHS directives, it offers industry certifications essential for safety and environmental compliance. It bears a rated AC voltage of 690V and a breaking capacity of 10 kA, with an ultimate breaking capacity (Icu) of 100 kA at 400 V.

With dimensions of 155 mm in height, 116 mm in width, and 155 mm depth, this compact Thermal Circuit Breaker supports DIN Rail mount installations efficiently in motor control panels. Additional slots allow for auxiliary contact blocks and voltage trip units integration for advanced control and signaling.

This product is ideal for industrial, commercial, and manufacturing motor protection applications and fits well within electrical control systems ensuring reliability and safe operation of three-phase motors.

Explore a wide range of Schneider Electric circuit breakers and electrical protection devices at EnvMart for your industrial automation and control needs. Provides thermal magnetic protection for motors. Adjustable thermal settings with dual tripping class.

Robust screw terminal connections with Everlink BTR. Complies with international electrical and safety standards. Compact design for DIN Rail mounting. Multiple advanced motor protection features included. Breaking capacity of 10 kA and rated for 690 V AC.
