RS PRO PCB Terminal Block 8-Contact 2.5 mm Pitch, 1 Row, Nylon Housing, 300V 4A 146-8339
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Grey |
| Orientation | Vertical |
| Current | 4A |
| Length | 21.5mm |
| Model | 146-8339 |
| Depth | 13mm |
| Width | 12mm |
| Housing Material | Nylon |
| Series | RS PRO |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Number of Contacts | 8 |
| Minimum Wire Size AWG | 20AWG |
| Maximum Wire Size AWG | 28AWG |
| Wire Connection Method | Spring Cage |
| RS PRO PCB Terminal Block, 8-Contact, 2.5 mm Pitch, 1 RowBrand | RS PRO |
Key Features
- Supports 8 contacts with 2.5 mm pitch in a single row configuration.
- Rated for 4A current and 300V voltage applications.
- Nylon housing made of UL94-V0 flame retardant PA66 material.
- Spring cage wire connection ensures secure and reliable clamping.
- Accommodates wire sizes from 28 AWG to 20 AWG solid cables.
- Vertical orientation with a grey colored housing for easy installation.
- Includes interlocking modules and 45 degree cable entry for flexibility.
- Lever actuator cable release for effortless wire insertion and removal.
Product Description
RS PRO 146-8339 is a high-quality PCB Terminal Block featuring 8 contacts arranged in a single row with a 2.5 mm pitch. Its design supports current ratings of up to 4A and voltage ratings of 300V, making it suitable for various electronic and electrical applications.
The housing is made from robust nylon material, moulded in flame retardant UL94-V0 rated PA66, providing excellent safety and durability under demanding industrial environments. The terminal block employs a spring cage wire connection method, which guarantees a secure and vibration-resistant electrical connection that simplifies wiring and maintenance.
Wires between 28 AWG and 20 AWG solid cables are compatible, accommodating typical PCB wiring needs. Its vertical orientation and grey color housing enable straightforward placement and identification on printed circuit boards.
The block features interlocking modules and a 45-degree cable entry design, allowing for flexible and efficient wiring setups. The lever actuator cable release mechanism enhances usability through easy wire insertion and quick release, reducing installation time.
This pcb terminal block measures 21.5 mm in length, with a width of 12 mm and a depth of 13 mm, ensuring compactness ideal for high-density PCB assembly. Certified with cRUus approval, this product meets stringent quality standards required in industrial, manufacturing, and electrical control systems.
This 8-contact terminal block is designed for industrial and commercial electronics use. Suitable for use in automation systems, control panels, and power distribution modules. Its reliable spring cage connection improves safety and reduces maintenance costs.
RS PRO products are trusted worldwide for consistent performance, and this terminal block exemplifies quality and safety for demanding applications. Explore the full RS PRO range on EnvMart for compatible connectors and accessories to complete your PCB assembly needs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block is rated for a maximum current of 4A and a voltage of 300V, making it suitable for various electronic applications.
It features 8 contacts arranged in a single row with a pitch of 2.5 mm.
This terminal block accommodates solid wire sizes ranging from 28 AWG to 20 AWG.
The housing is made from nylon, specifically UL94-V0 rated PA66, which is flame retardant.
It employs a spring cage wire connection method, ensuring a secure and vibration-resistant electrical connection.
The terminal block measures 21.5 mm in length, 12 mm in width, and 13 mm in depth.
It has a vertical orientation, which aids in straightforward placement on printed circuit boards.
Yes, it includes interlocking modules and a 45-degree cable entry design for flexible wiring setups, along with a lever actuator for easy wire insertion and release.
It is certified with cRUus approval, meeting stringent quality standards required in industrial and electrical control systems.
This model is suitable for use in automation systems, control panels, and power distribution modules.
The housing is grey, which aids in easy identification during installation.
This terminal block is manufactured in China.
