RS PRO PCB Terminal Block, 8-Contact, 2.5 mm Pitch, 1 Row, Nylon Housing, 4A, 300V, Grey 146-8255
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V |
| Brand | RS PRO |
| Colour | Grey |
| Orientation | Vertical |
| Current | 4A |
| Length | 21.5mm |
| Model | 146-8255 |
| Depth | 13mm |
| Width | 12mm |
| Housing Material | Nylon |
| Series | RS PRO |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Number of Contacts | 8 |
| Minimum Wire Size AWG | 20AWG |
| Maximum Wire Size AWG | 28AWG |
| Wire Connection Method | Spring Cage |
| RS PRO PCB Terminal Block, 8-Contact, 2.5 mm Pitch, 1 RowBrand | RS PRO |
Key Features
- The terminal block features a grey nylon housing with a flame retardant rating of UL94-V0 for enhanced safety.
- It supports a current rating of 4A and voltage rating of 300V, suitable for low-power electronic applications.
- Wire connections are secured via a spring cage mechanism, accommodating wire sizes from 28 AWG to 20 AWG.
- Compact dimensions of 21.5 mm length, 12 mm width, and 13 mm depth optimize PCB space usage.
- The vertical orientation and 1-row configuration facilitate easy installation and maintenance.
- Modular interlocking design supports 45-degree cable entry and lever actuator cable release for convenience.
- The product is cRUus approved and made in China, with compliance to standard safety requirements.
- It is ideal for industrial, electronic component assembly, automation systems, and control gear applications.
Product Description
RS PRO 146-8255 is a high-quality PCB terminal block featuring 8 contacts with a 2.5 mm pitch in a single-row layout. Constructed from durable nylon housing with UL94-V0 flame retardant rating, it offers safety and reliability for electronic circuit connections.
Designed with a spring cage wire connection method, it supports a wire range from 28 AWG to 20 AWG and operates safely up to 4A current and 300V voltage. Its compact size of 21.5 mm length, 12 mm width, and 13 mm depth ensures efficient usage of PCB real estate.
This terminal block is engineered with interlocking modules, a 45-degree cable entry angle, and lever actuator cable release features to facilitate easy installation and secure wiring. Vertically oriented and with cRUus approval, it meets industry standards for advanced electronic applications.
Suitable for a broad range of industrial, electronics manufacturing, automation, and control system functions, this RS PRO terminal block ensures durability and dependable electrical connections in challenging environments.
The terminal block features a grey nylon housing with a flame retardant rating of UL94-V0 for enhanced safety. It supports a current rating of 4A and voltage rating of 300V, suitable for low-power electronic applications.
Wire connections are secured via a spring cage mechanism, accommodating wire sizes from 28 AWG to 20 AWG. Compact dimensions of 21.5 mm length, 12 mm width, and 13 mm depth optimize PCB space usage. The vertical orientation and 1-row configuration facilitate easy installation and maintenance.
Modular interlocking design supports 45-degree cable entry and lever actuator cable release for convenience. The product is cRUus approved and made in China, with compliance to standard safety requirements. It is ideal for industrial, electronic component assembly, automation systems, and control gear applications.
Explore the comprehensive range of RS PRO electronic connectors and components at EnvMart for reliable and quality industrial electronics solutions.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block supports a current rating of 4A and a voltage rating of 300V, making it suitable for low-power electronic applications.
It features a pitch of 2.5 mm and has 8 contacts in a single-row configuration.
The terminal block can accommodate wire sizes ranging from 28 AWG to 20 AWG using a spring cage connection method.
The dimensions of this model are 21.5 mm in length, 12 mm in width, and 13 mm in depth.
The housing of this terminal block is made from nylon, which has a flame retardant rating of UL94-V0 for enhanced safety.
Wire connections are secured via a spring cage mechanism, ensuring a reliable connection.
This terminal block is designed with a vertical orientation, facilitating easy installation and maintenance.
Yes, it is cRUus approved, indicating compliance with standard safety requirements.
It is ideal for industrial, electronic component assembly, automation systems, and control gear applications.
The terminal block has a modular interlocking design that supports 45-degree cable entry and lever actuator cable release for convenience.
This model is manufactured in China.
