Block PCB Transformer 18 V AC Dual Secondary 2 Output Pin Mount FL 52/18

Block FL 52/18 PCB Transformer is a precision-engineered electrical component tailored for applications requiring dual secondary 18 V AC outputs. It supports primary inputs of 115 V AC and 230 V AC, making it suitable for international electronic equipment requiring robust voltage transformation with high safety and performance standards.

The transformer features a compact low-profile pin mounting configuration, making it ideal for PCB assembly in industrial electronics, power supplies, and automation equipment. The dimensions are precisely 86.5 mm in length, 49 mm in width, and 70 mm in depth, optimizing space without compromising power capability.

It offers a rated power capacity of 52 VA and operates efficiently in frequency ranges from 50 Hz to 60 Hz. The winding architecture includes dual secondary windings, allowing flexibility for series or parallel configurations depending on the circuit design needs.

Crafted using vacuum epoxy resin molding to UL94-V0 standard and glass fibre reinforced polyamide bobbins, this transformer ensures durability, electrical insulation, and low inter-winding capacitance which reduces noise in sensitive applications. It has an impressive isolation voltage rating of 5000 V to guarantee operational safety during high voltage conditions.

Compliant with stringent international standards such as IEC 61558-2-6, VDE 0570 Teil 2-4, IEC 61558-2-1 and others, this model is certified for quality and reliability in both industrial and laboratory environments. The product originates from Germany, reflecting premium manufacturing and engineering excellence.

Secondary voltage output of 18 V AC with dual secondary windings. Primary voltage supports 115 V AC and 230 V AC inputs for versatile power sources. Low profile pin mount design with compact dimensions optimized for PCB mounting.

Rated power of 52 VA with a maximum operating temperature of 40° C. Vacuum epoxy resin molding ensures UL94-V0 flame retardant rating. Complies with IEC and VDE safety and quality standards. Isolation voltage of 5000 V for high safety assurance.

Operates reliably at frequencies from 50 Hz to 60 Hz. Constructed with reinforced polyamide bobbins for durability. Designed for use in industrial electronics, power supplies, and control systems. Explore EnvMart for our broad selection of PCB Transformers and high-quality electronic components for your manufacturing and industrial requirements.
