TDK-Lambda KWS15A-24 Switching Power Supply 24V DC, 16.8W, 700mA Output, PCB Mount KWS15A-24

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda KWS15A-24 Switching Power Supply 24V DC, 16.8W, 700mA Output, PCB Mount KWS15A-24

Name: TDK-Lambda KWS15A-24 Switching Power Supply 24V DC, 16.8W, 700mA Output, PCB Mount KWS15A-24
Brand: TDK-Lambda
SKU: 394846
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand TDK-Lambda Condition New

Specifications

Country of Origin	Japan
Brand	TDK-Lambda
Power	16.8W
Efficiency	85%
Length	50.8mm
Model	KWS15A-24
Depth	24mm
Gross Weight	60g
Width	25.4mm
Mount Type	PCB
Series	KWS15A
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-10°C
Number of outputs	1
Maximum Input Voltage	370, 265V dc
Maximum Output Voltage	24V dc
SMPS Output Current	700mA
Minimum Input Voltage	85V ac

Key Features

Compact PCB mount design measuring 50.8mm length and 25.4mm width.
Universal input voltage range from 85V AC to 265V AC supports worldwide operation.
High efficiency of 85% reduces power loss and eases thermal management.
Output current rated at 700mA with maximum output voltage of 24V DC.
Operating temperature range from -10°C to 85°C for reliable performance.
Compliance with multiple international standards and approvals including CE, FCC Class B, and IEC/UL/CSA certifications.
Plastic UL94V-0 compliant housing ensures fire resistance and electrical insulation.
Equipped with overvoltage and overcurrent protection for safe operation.

Product Description

TDK-Lambda KWS15A-24 is a high-performance switching power supply designed for industrial, communication, test measurement, and broadcast applications. It provides a steady 24V DC output with a power rating of 16.8W and an output current of 700mA, ideal for space-constrained printed circuit board (PCB) mount installations.

This compact device features a length of 50.8mm, width of 25.4mm, and depth of 24mm, making it suitable for applications requiring minimal footprint without compromising reliability. The wide input voltage range from 85V AC to 265V AC allows usage in various global electrical environments. The unit operates efficiently at 85%, reducing power dissipation and easing thermal management challenges in installed systems.

Safety and compliance are integral to the KWS15A-24, meeting stringent electronic immunity and emission standards such as EN 61000 series, CE, FCC Class B, and IEC/UL/CSA/EN 62368-1. Its plastic case meets UL94V-0 flammability rating, assuring durable electrical insulation. Features include protection against overvoltage and overcurrent conditions, preserving connected electronics and prolonging service life.

Typical industrial applications include automation systems, communication devices, broadcast equipment, and laboratory instruments where stable 24V DC supply is crucial. The product's robust design ensures reliability under temperatures ranging from -10°C to 85°C, making it suitable for harsh environments.

Compact PCB mount form factor enhances integration flexibility. Wide input voltage range accommodates global power sources. High efficiency decreases thermal stress and energy loss. International compliance ensures interoperability and safety.

Robust protection features safeguard the power supply and load. Lightweight design benefits portable and space-sensitive installations.

Environmentally conscious design aligns with RoHS directives and offers reliable performance in demanding industrial and commercial electrical equipment. Explore more power supplies and electronic components in EnvMart's extensive electronics catalog for optimized system design.
