Wurth Elektronik 351 Series Pluggable Terminal Block, 8-Contact, 5.08 mm Pitch, 1 Row, 691351500008
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 300V ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Straight |
| Current | 20A |
| Length | 40.64mm |
| Depth | 15.1mm |
| Width | 18.2mm |
| Housing Material | Polyamide |
| Series | 351 |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Number of Contacts | 8 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.21mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Cable Entry |
Key Features
- The terminal block supports a maximum current of 20A for reliable performance.
- Constructed from durable polyamide housing material with green UL94-V0 PA66 rating.
- Compatible with wire sizes ranging from 0.21 mm² (24 AWG) to 3.31 mm² (12 AWG).
- Features a straight orientation with cable entry wire connection method.
- Rated for operational voltage up to 300V AC.
- Compact dimensions measuring 40.64 mm length, 18.2 mm width, and 15.1 mm depth.
- Includes tin-plated phosphor bronze wire guard for enhanced conductivity and corrosion resistance.
- Designed with a single row and male connector gender for versatility.
Product Description
Wurth Elektronik 691351500008 is a robust 351 Series Pluggable Terminal Block featuring 8 contacts with a 5.08 mm pitch arranged in one row. This component is engineered for secure and efficient electrical connection in a variety of industrial and commercial applications.
The terminal block housing is made from green polyamide material certified to UL94-V0 PA66 standards, ensuring excellent flame resistance and mechanical durability. It supports wire sizes from 0.21 mm² (24 AWG) up to 3.31 mm² (12 AWG) and operates at a voltage rating of 300V AC with a current carrying capacity of 20A.
The connector is designed with a male gender and features a straight orientation providing ease of cable entry connection. The internal tin-plated phosphor bronze wire guard guarantees reliable conductivity and protection against corrosion, extending the lifespan of the connection.
With compact dimensions of 40.64 mm length, 18.2 mm width, and 15.1 mm depth, the 691351500008 terminal block is suitable for applications where space efficiency is essential. It is manufactured in China with strict quality controls to meet industrial standards.
This pluggable terminal block is widely used in electronic components, power connectors, industrial automation, and PCB assembly tasks where reliable screw terminal connections with mating female sockets are required.
The terminal block supports a maximum current of 20A for reliable performance. Constructed from durable polyamide housing material with green UL94-V0 PA66 rating. Compatible with wire sizes ranging from 0.21 mm² (24 AWG) to 3.31 mm² (12 AWG).
Features a straight orientation with cable entry wire connection method. Rated for operational voltage up to 300V AC. Compact dimensions measuring 40.64 mm length, 18.2 mm width, and 15.1 mm depth. Includes tin-plated phosphor bronze wire guard for enhanced conductivity and corrosion resistance.
Designed with a single row and male connector gender for versatility. Manufactured in China ensuring quality and consistency. Ideal for industrial, electrical, and PCB connector applications. Explore the EnvMart catalog for more Wurth Elektronik terminal blocks and power connectors suitable for your industrial and electronic manufacturing needs.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this terminal block is 20A.
It is rated for an operational voltage of up to 300V AC.
This terminal block is compatible with wire sizes ranging from 0.21 mm² (24 AWG) to 3.31 mm² (12 AWG).
The dimensions of this terminal block are 40.64 mm in length, 18.2 mm in width, and 15.1 mm in depth.
The housing is constructed from polyamide material with a green UL94-V0 PA66 rating.
This model features a straight orientation with a cable entry wire connection method.
This terminal block has 8 contacts arranged in a single row.
The connector gender of this terminal block is male.
This terminal block is manufactured in China.
Yes, it includes a tin-plated phosphor bronze wire guard for enhanced conductivity and corrosion resistance.
The pitch of this terminal block is 5.08 mm.
