RS PRO Illuminated Push Button Switch Momentary Panel Mount SPST Red LED IP67 36V dc 250V ac 209-9120
Specifications
| Country of Origin | China |
|---|---|
| Brand | RS PRO |
| Model | 209-9120 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | RS PRO |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Switch Configuration | SPST |
| Minimum Operating Temperature | -35°C |
| Panel Cutout Size | 13.6 mm |
| Terminal type | Solder Lug |
| Standards/Approvals | RS |
| LED Colour | Red |
| Switch Operation | Momentary |
| Actuator Colour | Green |
| Contact DC Voltage | 36V dc |
| Actuator Style | Flat |
| Switch Contact Current | 125mA |
| Contact AC Voltage | 250V ac |
Key Features
- The switch features a 13.6 mm panel cutout size for compact mounting.
- It offers momentary switching operation with a flat dome actuator in green color.
- Rated for 36 V dc and 250 V ac voltages with a contact current of 125 mA.
- Constructed with Polyamide 6/6 material and gold over silver-plated contacts for durability.
- LED illumination is provided in red for clear status indication.
- IP67 protection rating ensures dust and water resistance for harsh environments.
- Mechanical life expectancy of 1,000,000 cycles supports long-term reliability.
- Operating temperature range spans from -35°C to 85°C for versatile usage conditions.
Product Description
RS PRO 209-9120 Illuminated Push Button Switch is a momentary, panel-mounted SPST switch designed for precise machine control and process activation. This sub-miniature switch features a red LED illumination and a green dome cap actuator constructed from high-quality Polyamide 6/6 material. It is rated for operation at 36 V dc and 250 V ac with a maximum contact current of 125mA.
The switch is sealed to IP67 standards, offering robust resistance against dust and moisture. Its compact 13.6 mm panel cutout size and flat actuator style allow for streamlined integration into control systems. Operating temperatures range from -35°C to 85°C, making it suitable for a variety of industrial environments.
The RS PRO 209-9120 switch utilizes gold over silver-plated contacts to ensure reliable conductivity and longevity, with a mechanical life expectancy of up to 1,000,000 cycles. The push-button operates momentarily, making it ideal for test equipment, telecommunications infrastructure, networking devices, and handheld appliances.
The panel mounting options include threaded or snap-in/press-fit designs, accommodating panel thicknesses from 1.5 mm to 4 mm. This product combines ease of installation with durability and high performance, making it a versatile solution for many electronics and electrical applications.
The switch has a 13.6 mm panel cutout, suitable for sub-miniature applications. Momentary switch operation provides precise control in machine automation. Red LED illumination enhances user interface clarity and status indication.
IP67 rating offers protection against dust ingress and splashing water. Robust mechanical life of 1,000,000 cycles ensures longevity in demanding conditions. Compatible with a wide operating temperature range from -35°C to 85°C.
Contact rating supports 36 V dc and 250 V ac for diverse applications. Manufactured with Polyamide 6/6 material for structural strength. Gold over silver-plated contacts ensure excellent electrical performance. Ideal for use in telecommunications, networking, test equipment, and handheld devices.
Explore more RS PRO products and Push Button Switches on EnvMart for industrial, laboratory, and commercial electrical applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 85°C.
This switch requires a panel cutout size of 13.6 mm for installation.
The contact current rating for this switch is 125 mA.
It supports a contact DC voltage of 36V and an AC voltage of 250V.
This model uses a Single Pole Single Throw (SPST) switch configuration.
The switch has an IP67 rating, providing protection against dust and water ingress.
It is constructed from Polyamide 6/6 material and features gold over silver-plated contacts.
The mechanical life expectancy of this model is up to 1,000,000 cycles.
The LED illumination on this switch is red.
The minimum operating temperature for this switch is -35°C.
This model features a flat actuator style in green color.
The switch can be mounted using threaded or snap-in/press-fit designs, accommodating panel thicknesses from 1.5 mm to 4 mm.
