Bourns Non-Resettable Fuse 1A, 125V AC Ceramic Body High Inrush Speed SF-2410HI100T-2

Bourns SF-2410HI100T-2 is a Non-Resettable Fuse rated at 1A and 125V AC, designed with a ceramic body for high inrush applications. This fuse features a single blow operation, effectively protecting circuits from overcurrent conditions. The surface mount packaging enables automated assembly, facilitating efficient manufacturing processes.

The fuse has a compact size with a width and height of 2.6mm and a depth of 6.1mm, making it suitable for space-constrained electronic devices. Its high breaking capacity of 300A ensures reliable protection under demanding conditions. The ceramic material provides excellent thermal stability with a minimum operating temperature of 125°C and a maximum operating temperature of -55°C.

This component is halogen free and meets RoHS and UL 248-14 standards, making it environmentally compliant and suitable for modern electronic applications. It is widely used in notebooks, LCD monitors, LCD backlight inverters, POE and POE+ systems, PC servers, power supplies, battery protection circuits, and white goods.

The fuse series SF-2410HI-T offers consistent resistance of 107.9 milliohms, supporting stable performance. Manufactured in Taiwan, Province Of China, this fuse is part of a high-quality range trusted in industrial and consumer electronics.

Single blow fuse provides effective overcurrent protection. Ceramic tube construction ensures durability and high temperature resistance. Surface mount package type suitable for automated assembly. High breaking capacity of 300A for demanding applications.

Compact dimensions of 2.6mm width, 2.6mm height, and 6.1mm depth. Minimum operating temperature of 125°C and maximum operating temperature of -55°C. Halogen free design complies with environmental standards. RoHS and UL 248-14 certified for compliance.

Ideal for use in notebooks, LCD monitors, power supplies, and battery protection applications. Manufactured in Taiwan, Province Of China. Explore more electrical protection devices and fuses at EnvMart, ensuring the right fit for your electronic and industrial needs.
