KEMET SPST Through Hole Reed Switch 300 mA 110 V ac/dc OHD3-125M

KEMET OHD3-125M SPST Through Hole Reed Switch provides reliable switching with a maximum current capacity of 300 mA and voltage handling of 110 V ac/dc, ideal for precision electrical control applications.

This switch incorporates a single-pole single-throw (SPST) contact configuration that ensures simple and efficient operation for various circuit designs. Constructed with nickel iron alloy contacts, the device guarantees excellent durability and minimal contact resistance rated at 150 mΩ, optimizing electrical performance.

The through hole mount design equipped with tab leads offers straightforward installation on printed circuit boards, facilitating manufacturing assembly processes. The compact size with dimensions of 27 mm in length, 13.5 mm in width, and 12.5 mm in depth makes it suitable for space-constrained applications.

Operating temperature range from -20°C to 150°C allows usage in diverse industrial, automation, and electrical environments. This device complies with international safety and environmental standards including TUV, CSA, UL, and RoHS, ensuring adherence to regulatory requirements.

Typical applications include atmospheric temperature detection, overheating monitoring in power transistors, power modules, room heaters, hot gas heaters, PPCs, amplifiers, motors, hard disk drives, and floppy disk drives among other electrical appliances.

The switch uses SPST contact configuration for reliable operation. Supports maximum switching current of 300 mA and power of 6 W. Low contact resistance at 150 mΩ enhances electrical efficiency. Durable nickel iron alloy contact material ensures long service life.

Through hole mount with tab leads for easy PCB installation. Wide temperature range of -20°C to 150°C suits varied environments. Compact physical dimensions allow use in limited space applications. Certified compliant with TUV, CSA, UL, and RoHS standards.

Manufactured in Japan to high-quality standards.
