LDK M6 Female 304 Stainless Steel Rod End with 6mm Bore, Left Hand Thread, PTFE Composite Race SPHS6ECL
Specifications
| Country of Origin | China |
|---|---|
| Brand | LDK |
| Material | 304 Stainless Steel |
| Model | SPHS6ECL |
| Body | 304 Stainless steel |
| BALL | 440C Stainless Steel, heat treated, HRC56 min Precision ground, polished |
| Overall Width | 39mm |
| Outside diameter | 18mm |
| Connection Size | M6 Female |
| Bore Diameter | 6mm |
| Thread Standard | Metric |
| Static Load Rating | 7.8kN |
| Thread Direction | Left Hand |
| Dynamic Load Rating | 4.7kN |
| Connection Gender | Female |
| Race | PTFE composite |
| Sliding contact surfaces | Steel/PTFE composite |
Key Features
- Manufactured from corrosion-resistant 304 stainless steel body for durability.
- Equipped with a precision ground, polished 440C stainless steel ball with HRC 56 minimum hardness.
- PTFE composite race and steel/PTFE composite sliding contact surfaces reduce friction.
- Designed with an M6 female connection and a 6mm bore for metric threading.
- Rated for dynamic load of 4.7 kN and static load of 7.8 kN, suitable for industrial use.
- Overall width of 39 mm and outside diameter of 18 mm optimize fit in assemblies.
- Left hand thread direction enhances specialized fastening requirements.
Product Description
LDK SPHS6ECL is a female rod end bearing made from 304 stainless steel, featuring a 6mm bore with a metric M6 left hand thread connection. The ball is crafted from heat-treated 440C stainless steel with a minimum hardness of HRC 56, precision ground and polished to ensure smooth operation. This rod end uses a PTFE composite race and steel/PTFE composite sliding surfaces to minimize friction, making it highly reliable for rotary bearing applications.
This stainless steel rod end is ideal for a wide range of industrial, mechanical, fluid power, and tooling applications that require robust and corrosion-resistant components. Its dynamic load rating of 4.7 kN and static load rating of 7.8 kN ensure it can withstand demanding mechanical stresses. The overall width of 39 mm and outside diameter of 18 mm ensure accurate fit and function within assemblies.
The left hand thread enables secure fastening where reverse threading is necessary, adding to the versatility of this rod end in pneumatic, hydraulic, manufacturing, and construction equipment platforms.
Constructed for durability and precision, the SPHS6ECL rod end is suited for industrial machinery and equipment requiring high-quality rotary bearings with stainless steel construction for corrosion resistance.
Manufactured from corrosion-resistant 304 stainless steel body for durability. Equipped with a precision ground, polished 440C stainless steel ball with HRC 56 minimum hardness. PTFE composite race and steel/PTFE composite sliding contact surfaces reduce friction.
Designed with an M6 female connection and a 6mm bore for metric threading. Rated for dynamic load of 4.7 kN and static load of 7.8 kN, suitable for industrial use. Overall width of 39 mm and outside diameter of 18 mm optimize fit in assemblies.
Left hand thread direction enhances specialized fastening requirements. Explore the full range of precision Rod Ends with LDK at EnvMart for reliable rotary bearing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The dynamic load rating of this rod end is 4.7 kN.
It is made from 304 stainless steel, providing corrosion resistance and durability.
The overall width is 39 mm and the outside diameter is 18 mm.
This rod end features a left hand thread with a metric M6 female connection.
The static load rating is 7.8 kN.
The bore diameter of this model is 6 mm.
It uses steel/PTFE composite sliding contact surfaces to reduce friction.
The ball is made from heat-treated 440C stainless steel with a minimum hardness of HRC 56.
This rod end is manufactured in China.
It is suitable for industrial, mechanical, fluid power, and tooling applications that require robust components.
It features a PTFE composite race, which helps in minimizing friction during operation.
Yes, it is designed for reliable use in rotary bearing applications due to its construction and materials.
