Eaton PFIM Series Residual Current Device 63A 4-Pole 300mA Type A 10kA Breaking Capacity 230V 400V 235445 PFIM-63/4/03-A-MW
Specifications
| Country of Origin | Romania |
|---|---|
| Range | PFIM |
| Brand | Eaton |
| Height | 80mm |
| Model | 235445 PFIM-63/4/03-A-MW |
| Depth | 70.5mm |
| Width | 65.5mm |
| Mount Type | DIN Rail |
| Current Rating | 63A |
| Series | PFIM |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 4 |
| Standards/Approvals | IEC/EN 61008 |
| Rated AC Voltage | 230, 400V |
| Tripping Characteristics | Type A |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 300mA |
| Break Time | Instantaneous |
Key Features
- Designed for industrial fault current and residual current protection.
- Features a 10kA breaking capacity for safe disconnection during faults.
- Instantaneous break time with electromagnetic tripping mechanism.
- Mounts easily on DIN rails with screw terminal connections.
- Operates at rated voltages of 230V and 400V AC.
- Incorporates a toggle switch reset actuator for user-friendly operation.
- Complies with IEC/EN 61008 standards for safety and reliability.
- Manufactured in Romania ensuring high quality standards.
Product Description
Eaton 235445 PFIM-63/4/03-A-MW Residual Current Device (RCD) is a professional-grade compact protective device rated at 63A and featuring 4 poles for comprehensive circuit protection. It has a trip sensitivity of 300mA and Type A tripping characteristics, making it suitable for industrial applications requiring fault current and residual current protection.
This model has a breaking capacity of 10 kA and operates at rated AC voltages of 230V and 400V. Its electromagnetic tripping mechanism ensures instantaneous disconnection in case of fault conditions, enhancing safety and equipment protection.
The device is designed for DIN rail mounting and includes screw terminals for secure and reliable electrical connections. Compact dimensions of 80mm height, 70.5mm depth, and 65.5mm width allow flexible installation in various industrial panels and switchboards.
Additional features include a toggle switch actuator for easy manual reset and a real contact position indicator for clear operational status. Eaton's PFIM Series complies with IEC/EN 61008, ensuring high safety standards and regulatory compliance.
Manufactured in Romania, this Residual Current Device is ideal for use in industrial, commercial, electrical distribution, and automation applications where personnel and equipment safety is critical.
Designed for industrial fault current and residual current protection. Features a 10kA breaking capacity for safe disconnection during faults. Instantaneous break time with electromagnetic tripping mechanism. Mounts easily on DIN rails with screw terminal connections.
Compact dimensions: 80mm height, 70.5mm depth, and 65.5mm width. Operates at rated voltages of 230V and 400V AC. Incorporates a toggle switch reset actuator for user-friendly operation. Complies with IEC/EN 61008 standards for safety and reliability.
Manufactured in Romania ensuring high quality standards. Explore more Eaton electrical protection devices within the EnvMart collection for reliable and certified circuit management solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a breaking capacity of 10kA, ensuring safe disconnection during fault conditions.
It operates at rated voltages of 230V and 400V AC, making it suitable for various industrial applications.
The trip sensitivity of this device is 300mA, which is designed for effective fault current protection.
This model has 4 poles, providing comprehensive circuit protection for industrial applications.
It utilizes an electromagnetic tripping mechanism that ensures instantaneous disconnection in case of faults.
The dimensions are 80mm in height, 70.5mm in depth, and 65.5mm in width, allowing for flexible installation.
It features a toggle switch reset actuator for user-friendly operation and manual resetting.
Yes, it complies with IEC/EN 61008 standards, ensuring safety and reliability in its operation.
It is designed for DIN rail mounting, which facilitates easy installation in various panels.
This model is ideal for industrial, commercial, electrical distribution, and automation applications where safety is critical.
It is manufactured in Romania, ensuring adherence to high quality standards.
It includes screw terminals for secure and reliable electrical connections during installation.
