Eaton PKNM Series Residual Current Device 6A 2-Pole 30mA Type B 10kA 230V AC 236012 PKNM-6/1N/B/003-A-MW
Specifications
| Country of Origin | Romania |
|---|---|
| Range | PKNM |
| Brand | Eaton |
| Height | 80mm |
| Model | 236012 PKNM-6/1N/B/003-A-MW |
| Depth | 70.5mm |
| Width | 70mm |
| Mount Type | DIN Rail |
| Current Rating | 6A |
| Series | PKNM |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Standards/Approvals | IEC/EN 61008 |
| Rated AC Voltage | 230V ac |
| Tripping Characteristics | Type B |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 30mA |
| Break Time | Instantaneous |
| Eaton RCBO, 6A Current Rating, 1P+N Poles, Type BBrand | Eaton |
Key Features
- Designed for industrial applications requiring sensitive earth fault protection.
- Features 2 poles and trip sensitivity of 30mA to prevent electric shock hazards.
- Mounted on DIN rail with screw terminals for secure installation.
- Breaking capacity of 10kA and instantaneous break time for rapid disconnection.
- Equipped with toggle switch reset actuator and electromagnetic tripping mechanism.
- Compact dimensions with height 80mm, width 70mm, and depth 70.5mm for efficient panel integration.
- Conforms to IEC/EN 61008 standards ensuring reliable operation and compliance.
- Includes red and green contact position indicators for clear device status visualization.
Product Description
Eaton 236012 PKNM-6/1N/B/003-A-MW Residual Current Device (RCD) is engineered to provide precise and reliable protection against electric shock in industrial and commercial electrical installations. The device monitors current flow and automatically disconnects the circuit upon detecting an imbalance to safeguard users and equipment.
This 6A rated RCD features 2 poles and offers a trip sensitivity of 30mA with Type B tripping characteristics, enabling it to detect AC, pulsating DC, and smooth DC residual currents. Its high breaking capacity of 10kA ensures robust interruption capability under fault conditions.
Installation is simplified by DIN rail mounting and screw terminal types, making it compatible with standard switchboards. The instantaneous break time and electromagnetic tripping mechanism facilitate rapid disconnection for enhanced safety.
The device dimensions - height 80mm, width 70mm, depth 70.5mm - ensure space-efficient panel integration. Users benefit from the toggle switch reset actuator and clear red-green contact position indicator, which provides visual confirmation of status.
Conforming to IEC/EN 61008 standards, this residual current device meets stringent quality and safety requirements. It is particularly suitable for environments where protection against electric shock and fire risk from earth faults is critical.
Manufactured in Romania, the Eaton PKNM series is known for its professional grade quality and durability, making it ideal for industrial, construction, HVAC, and manufacturing applications.
Designed for industrial safety and electrical protection. Permanent monitoring of current flow to detect leakage faults. Compact and robust design for panel mounting. High sensitivity to earth fault currents with Type B characteristics.
Reliable and compliant with international electrical standards. Explore more products in the Residual Current Device category for comprehensive electrical protection solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 6A.
It features a trip sensitivity of 30mA, designed to prevent electric shock hazards.
The device has a height of 80mm, a width of 70mm, and a depth of 70.5mm.
It has a breaking capacity of 10kA, providing robust interruption capability under fault conditions.
It is designed for DIN rail mounting, facilitating secure installation in standard switchboards.
This unit has Type B tripping characteristics, enabling it to detect AC, pulsating DC, and smooth DC residual currents.
It is equipped with a toggle switch reset actuator for easy resetting after a trip.
It conforms to IEC/EN 61008 standards, ensuring reliable operation and compliance with safety requirements.
The tripping mechanism is electromagnetic, allowing for instantaneous disconnection during fault conditions.
It features screw terminals, which provide secure connections during installation.
This device is manufactured in Romania.
It is particularly suitable for industrial, construction, HVAC, and manufacturing applications where protection against electric shock and fire risk from earth faults is critical.
