Eaton PFIM Series Residual Current Device 40A 2-Pole 300mA Type AC 10kA Breaking Capacity 230V/400V 235396 PFIM-40/2/03-MW
Specifications
| Country of Origin | India |
|---|---|
| Range | PFIM |
| Brand | Eaton |
| Height | 80mm |
| Model | 235396 PFIM-40/2/03-MW |
| Depth | 70.5mm |
| Width | 65.5mm |
| Mount Type | DIN Rail |
| Current Rating | 40A |
| Series | PFIM |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Standards/Approvals | RoHS |
| Rated AC Voltage | 230, 400V |
| Tripping Characteristics | Type AC |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 300mA |
| Break Time | Instantaneous |
Key Features
- This device features Type AC tripping characteristics for reliable residual current detection.
- Designed for DIN Rail mounting with screw terminal type for secure connections.
- Has a breaking capacity of 10kA and instantaneous break time for safety and protection.
- Compact dimensions of 80mm height, 70.5mm depth, and 65.5mm width for space-efficient installation.
- Equipped with a toggle switch reset actuator type and electromagnetic tripping mechanism for ease of use.
- Suitable for 230V and 400V rated AC voltage industrial applications.
- RoHS compliant and designed for professional electrical fault and residual current protection.
Product Description
Eaton 235396 PFIM-40/2/03-MW Residual Current Device is a professional-grade electrical safety component designed to provide reliable residual current protection with a 40A current rating and 2 poles. Featuring a trip sensitivity of 300mA and Type AC tripping characteristics, this device ensures rapid fault current detection and interruption to protect industrial electrical systems.
The device is engineered for DIN Rail mounting, facilitating compact and efficient installation in control panels and distribution boards. It incorporates screw terminal connections to secure wiring firmly and withstand electrical stresses.
This residual current device offers a high breaking capacity of 10kA and provides instantaneous break time, ensuring fast disconnection under fault conditions. Its compact physical dimensions (80mm height, 70.5mm depth, 65.5mm width) allow for usage in space-constrained installations.
The reset mechanism utilizes a toggle switch actuator, and the electromagnetic tripping mechanism guarantees consistent and reliable performance. Rated for 230V and 400V AC supply voltages, this device complies with RoHS standards, making it suitable for industrial, commercial, and manufacturing electrical protection applications.
Its robust construction and precise sensitivity make it ideal for fault current monitoring, improving safety in electrical distribution networks. Eaton, a trusted name in electrical components, ensures quality and durability in the PFIM series.
This device features Type AC tripping characteristics for reliable residual current detection. Designed for DIN Rail mounting with screw terminal type for secure connections. Has a breaking capacity of 10kA and instantaneous break time for safety and protection.
Compact dimensions of 80mm height, 70.5mm depth, and 65.5mm width for space-efficient installation. Equipped with a toggle switch reset actuator type and electromagnetic tripping mechanism for ease of use. Suitable for 230V and 400V rated AC voltage industrial applications.
RoHS compliant and designed for professional electrical fault and residual current protection. Explore more Residual Current Devices and circuit protection products on EnvMart for diverse electrical and industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 40A.
The compact dimensions are 80mm in height, 70.5mm in depth, and 65.5mm in width.
It has a breaking capacity of 10kA, ensuring effective disconnection under fault conditions.
It is designed for DIN Rail mounting, which allows for efficient installation in control panels.
This device utilizes an electromagnetic tripping mechanism for reliable operation.
The trip sensitivity is set at 300mA, providing effective fault current detection.
It is suitable for both 230V and 400V rated AC voltage applications.
It is equipped with a toggle switch reset actuator for ease of use.
This device features Type AC tripping characteristics for reliable residual current detection.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
Wiring is secured using screw terminal connections, which withstand electrical stresses.
This model belongs to the PFIM series, which is designed for professional electrical protection applications.
