Eaton PFIM Series Residual Current Device 63A 4-Pole 30mA Type A 10kA Breaking Capacity 235443 PFIM-63/4/003-A-MW

Eaton 235443 PFIM-63/4/003-A-MW Residual Current Device is engineered for reliable protection against residual currents in electrical installations. It features a 63A current rating and a 4-pole configuration, suitable for 230V AC to 400V AC voltage ranges commonly found in residential and commercial environments.

Its Type A trip sensitivity of 30mA ensures protection against both AC and pulsating DC residual currents, surpassing the capability of basic Type AC devices. The device incorporates an electromagnetic tripping mechanism with instantaneous break time, facilitating rapid disconnection in fault conditions.

This RCD from the PFIM series is designed for DIN rail mounting, allowing space-efficient and secure installation within electrical control panels. It includes a toggle switch reset actuator and screw terminals for sturdy, reliable connections. The contact position indicator provides a clear visual status of the device, enhancing operational safety.

With a breaking capacity of 10kA, the device can safely interrupt high fault currents, protecting wiring and connected equipment from damage. The compact dimensions of 80mm height, 70.5mm depth, and 65.5mm width enable installation in confined spaces while maintaining compliance with IEC/EN 61008 standards.

The unit's IP20 rating indicates it is touch-proof, preventing accidental contact with live parts. This model is manufactured in Romania and is ideally suited for commercial and residential electrical protection applications where earth leakage detection is critical.

Designed for DIN rail mounting for quick and compact installation. Type A tripping characteristic suitable for AC and pulsating DC residual currents. 10kA breaking capacity ensures reliable interruption of fault currents.

Equipped with toggle switch reset actuator and screw terminal connections. Compact dimensions enable space-saving panel integration. Electromagnetic tripping mechanism with instantaneous break time. IP20 touch-proof rating for enhanced user safety.

Contact position indicator to show operational status clearly. Complies with IEC/EN 61008 standards for Residual Current Devices. Ideal for residential and commercial earth leakage protection. Explore Eaton’s range of Residual Current Devices in the Circuit Breakers & Fuse category at EnvMart for comprehensive electrical safety solutions.
