Microchip Split Gate 64 MB SPI Flash Memory 8-Pin WDFN SST26VF064B-104I/MF

Free Delivery in India | Lowest Global Shipping Charges

Microchip Split Gate 64 MB SPI Flash Memory 8-Pin WDFN SST26VF064B-104I/MF

Name: Microchip Split Gate 64 MB SPI Flash Memory 8-Pin WDFN SST26VF064B-104I/MF
Brand: Microchip
SKU: 383084
Price: 5.29 USD
Availability: InStock



Category Semiconductor Memory Brand Microchip Condition New

Specifications

Country of Origin	India
Brand	Microchip
Height	750μm
Length	6mm
Cell Type	Split Gate
Model	SST26VF064B-104I/MF
Width	6mm
Mount Type	Surface
Series	SST26VF064B
Maximum Operating Temperature	85°C
Package Type	WDFN
Minimum Operating Temperature	-40°C
Memory size	64MB
Interface Type	SPI
Pin Count	8
Automotive Standard	AEC-Q100
Maximum Supply Voltage	3.6V
Minimum Supply Voltage	2.7V
Supply Current	20mA
Maximum Clock Frequency	104MHz
Organisation	8M x 8 Bit
Number of Bits per Word	8
Maximum Random Access Time	3ns
Number of Words	8K
Microchip 64Mbit SPI Flash Memory 8-Pin TDFN, SST25VF064C-80-4I-Q2AEBrand	Microchip

Key Features

Memory size of 64MB suitable for high-density memory applications.
Interface supports SPI protocol with a maximum clock frequency of 104 MHz.
Low power consumption with active read current at 15 mA typically.
Operates within a wide supply voltage range of 2.7V to 3.6V.
Surface mount device with compact 6mm x 6mm dimensions and 750μm height.
Operating temperature range from -40°C to 85°C for industrial applications.
Fast erase times with sector/block erase typically at 18 ms and chip erase at 35 ms.
Automotive grade compliance with AEC-Q100 standard ensuring reliability.

Product Description

Microchip SST26VF064B-104I/MF is a 64MB Split Gate SPI Flash Memory in an 8-Pin WDFN surface mount package. Designed for industrial and automotive applications, it features a high clock frequency of up to 104 MHz enabled by Microchip's Serial Quad I/O technology. This flash memory device supports SPI protocol and offers low power consumption suitable for battery-powered devices.

The device has a robust operating voltage range between 2.7V and 3.6V inclusive, with an operational temperature range extending from -40°C to 85°C. It employs SuperFlash® technology enabling exceptionally fast sector and chip erase times of typically 18 ms and 35 ms respectively, improving system efficiency.

With a compact 6mm by 6mm footprint and a height of 750 μm, this memory chip is ideal for space-constrained embedded systems. The SST26VF064B series supports execute-in-place (XIP), reducing processor buffer requirements and latency during code execution.

This product meets the automotive standard AEC-Q100, ensuring high reliability and ruggedness for automotive electronics. It features split gate cell architecture, providing endurance and data retention advantages over traditional flash memories.

High-speed SPI interface with up to 104 MHz clock frequency. Low power active read at 15 mA and standby current as low as 15 μA. Fast erase operations improving programming cycles and system responsiveness. Compact WDFN package ideal for automated PCB assembly and low profile applications.

Wide temperature range suitable for demanding industrial and automotive environments. Supports standard SPI commands ensuring compatibility with existing systems. 8M x 8-bit organization providing 64MB of memory capacity.

Maximum random access time of 3 nanoseconds enabling quick data access.

This Microchip flash memory device supports a wide range of industrial, automotive, embedded, and communication applications. It is best suited for firmware storage, boot code, and data logging solutions where low power and high performance are necessary.

Explore more in the Semiconductor - Semiconductor Memory category at EnvMart to find compatible components and accessories from trusted brands like Microchip.
