TRACOPOWER Switching Regulator Through Hole 6.5V DC Output Voltage 1A Output Current TSR 1-2465SM

TRACOPOWER TSR 1-2465SM Switching Regulator is a through hole mounted voltage regulator designed to deliver a stable 6.5V DC output voltage with a maximum output current of 1 ampere. This high-efficiency switching regulator achieves up to 93% efficiency enabling full load operation up to +65°C ambient temperature without requiring an additional heat transmission layer.

The TSR 1-2465SM series offers significantly improved output voltage accuracy of ±2%, alongside a low standby current, making it ideal for power-sensitive and battery-powered applications. Encased in a compact TO-220 package measuring 11.7mm in length, 10.2mm width, and 7.6mm depth, it supports through-hole mounting for robust PCB installation.

Operating across a wide input voltage range from 9V to 36V DC, this regulator features built-in filter capacitors to reduce ripple and noise to 75mV, and it maintains excellent line regulation at 0.2% and load regulation at 0.6%. Additionally, it includes short circuit protection to safeguard the connected circuitry and enhance device longevity.

The device supports operation within a wide temperature range from -40°C to +85°C, making it suitable for various industrial, electronic, and commercial applications requiring reliable power management.

With a mean time between failures (MTBF) of approximately 5,350,000 hours, the TSR 1-2465SM showcases high reliability, backed by compliance with RoHS standards ensuring environmentally safe components.

High efficiency of 93% with no need for heat transmission layer. Stable 6.5V DC output at up to 1A current. Wide operating temperature range from -40°C to +85°C. Compact TO-220 package suitable for through hole mounting.

Built-in filter capacitors reduce output ripple and noise to 75mV. Short circuit protection for enhanced safety. Excellent line and load regulation for power stability. Wide input voltage range from 9V to 36V DC. Low standby current ideal for battery powered applications.

MTBF of 5,350,000 hours ensures product durability and reliability.

This switching regulator is widely used for industrial, electronic components, power supplies, and voltage conversion applications, providing efficient and reliable power management. It is particularly suitable where compact size and stable voltage output are essential. Explore more products in our Switching Regulators category for additional solutions.
