Crouzet em4 Local Series PLC CPU with 16 Digital and Analogue Inputs, 10 Relay Outputs, Panel Mount, Modbus RS485 88981103

Crouzet 88981103 em4 Local Series PLC CPU is designed for industrial automation with a combination of 16 digital and analogue inputs paired with 10 relay outputs. It supports panel mounting and utilizes the Modbus RS485 communication protocol with accessory support to enable robust networked control systems.

This nano-PLC offers programming via Function Block Diagram (FBD) and Sequential Function Chart (SFC), providing flexibility in control logic implementation. Its battery backup ensures program integrity during power interruptions, enhancing reliability in critical automation processes.

The device operates within a temperature range of -20°C to 60°C, suitable for diverse industrial environments. With a compact footprint of 124.6 mm length, 90 mm width, and 60.4 mm depth, it integrates seamlessly into control panels.

The integrated display consists of four lines with 18 characters each for clear operational feedback. It meets international standards including IEC/EN 61000-6-1, CE, and cULus, guaranteeing compliance with essential safety and EMC regulations.

Applications of this PLC include automation control in manufacturing, process control, HVAC systems, and industrial equipment monitoring. Its Modbus communication facilitates integration into larger industrial networks promoting efficient data exchange and remote operation.

Supports both digital and analogue input types for flexible sensor integration. Equipped with 10 relay outputs ensuring reliable switching operations. Panel mount design facilitates easy and secure installation. Integrated Modbus RS485 communication port with accessory support for network connectivity.

Programmable with Function Block Diagram (FBD) and Sequential Function Chart (SFC) languages. Includes battery backup to preserve program data during power loss. Operating temperature range from -20°C to 60°C for industrial environment suitability.

Features a highly visual display with 4 lines and 18 characters per line for clear monitoring. Compact dimensions: length 124.6 mm, width 90 mm, depth 60.4 mm. Conforms to IEC/EN 61000-6-1, CE, and cULus standards ensuring electrical safety.
