Schurter DIN Rail RFI Filter 6A 250V AC 50Hz/60Hz 2-Stage Single Phase Screw Termination 5500.2269
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schurter |
| Height | 48mm |
| Length | 102mm |
| Depth | 61mm |
| Mount Type | DIN Rail |
| Operating Frequency | 50, 60Hz |
| Series | FMAC RAIL |
| Maximum Operating Temperature | 100°C |
| Number Of Stages | 2 |
| Resistance | 1mΩ |
| Capacitance | 100nF |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 6A |
| Number of Phases | 1 |
| Leakage Current | 250μA |
| Maximum Voltage | 250V ac |
| Inductance | 2mH |
| Standards/Approvals | EN 60950 |
| Termination Style | Screw |
Key Features
- Designed for DIN rail mounting with screw termination for secure installation.
- Operates efficiently at 50Hz and 60Hz frequencies.
- Constructed in a robust metal housing for durability in electric switch and control cabinets.
- Effective against symmetrical and asymmetrical interferences between 10kHz and 30MHz.
- Complies with EN 60950 standards ensuring quality and safety.
Product Description
Schurter 5500.2269 DIN Rail RFI Filter is a high-quality two-stage single-phase power line filter designed for DIN rail mounting. It supports a maximum current of 6A and a maximum voltage of 250V AC, operating across standard industrial frequencies of 50Hz and 60Hz. This filter is specifically engineered for industrial environments, particularly electric switch and control cabinets, where electromagnetic interference (EMI) mitigation is critical.
The filter features screw termination for reliable electrical connections and is housed within a durable metal casing that ensures robust performance and protection.
Its design is highly effective against both symmetrical and asymmetrical interference within the frequency range of 10kHz to 30MHz, providing broad band attenuation to protect sensitive electronic equipment.
Dimensionally, the filter measures 102mm in length, 61mm in depth, and 48mm in height, making it suitable for compact installations on DIN rails.
Compliance with EN 60950 confirms the filter’s adherence to international safety and performance standards, making it a dependable choice for industrial, manufacturing, electrical distribution, and HVAC applications.
Designed for secure DIN rail mount installation with screw termination. Supports a maximum current of 6 amperes for moderate load applications. Operates efficiently on common industrial AC frequencies of 50 and 60 Hz. Effective attenuation of EMI in frequency range 10kHz to 30MHz.
Compact metal housing dimensions: 102mm x 61mm x 48mm (LxDxH).
This Schurter model 5500.2269 RFI filter is an ideal component for enhancing electromagnetic compatibility (EMC) in various industrial electronic systems, ensuring compliance with relevant standards and improving system reliability.
Explore EnvMart’s comprehensive catalog for a wide selection of EMI and RFI filters designed for diverse industrial and commercial applications.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 6A.
This unit measures 102mm in length, 61mm in depth, and 48mm in height.
It supports a maximum voltage of 250V AC.
It operates efficiently at standard frequencies of 50Hz and 60Hz.
The filter features screw termination for reliable electrical connections.
It is effective against symmetrical and asymmetrical interference in the frequency range of 10kHz to 30MHz.
The minimum operating temperature is -25°C, while the maximum is 100°C.
It complies with EN 60950 standards, ensuring quality and safety.
This model is designed for DIN rail mounting.
The inductance value is 2mH.
The capacitance value is 100nF.
It is suitable for use in electric switch and control cabinets, as well as in various industrial environments.
