Schurter Single Phase DIN Rail Mounted RFI Filter 20A 250V AC 50Hz/60Hz FMAB RAIL 5500.2262
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schurter |
| Height | 48mm |
| Length | 102mm |
| Depth | 61mm |
| Mount Type | DIN Rail |
| Operating Frequency | 50, 60Hz |
| Series | FMAB RAIL |
| Maximum Operating Temperature | 100°C |
| Number Of Stages | 1 |
| Capacitance | 68nF |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 20A |
| Number of Phases | 1 |
| Leakage Current | 2.1mA |
| Maximum Voltage | 250V ac |
| Inductance | 25mH |
| Termination Style | Screw |
Key Features
- Designed for DIN rail mounting with screw termination for secure installation.
- Operates efficiently at 50Hz and 60Hz frequencies for versatile AC power networks.
- Provides filtering against asymmetrical interferences in the 100kHz to 30MHz frequency range.
- Constructed in a metal housing ensuring durability in industrial environments.
- Compact dimensions of 102mm length, 61mm depth, and 48mm height optimize panel space.
- Capacitance of 68nF and inductance of 25mH for effective EMI suppression.
- Leakage current is low at 2.1mA enhancing safety and compliance.
- Operating temperature range is broad from -25°C to 100°C for reliable performance.
Product Description
Schurter 5500.2262 is a high-quality single phase RFI filter designed for DIN rail mounting in industrial and electrical switching control cabinets. Rated at 20A and 250V AC, it is purpose-built to suppress radio frequency interference, especially effective against asymmetrical disturbances in the frequency range of 100kHz to 30MHz.
The filter utilizes a metal chassis housing and screw termination style, allowing for secure and reliable mechanical and electrical connections on standard DIN rails. Its compact size (102mm x 61mm x 48mm) ensures efficient use of cabinet space while maintaining robust electromagnetic compatibility.
Operating at both 50Hz and 60Hz frequencies, this Schurter FMAB RAIL series filter supports a wide range of AC power applications in industrial, manufacturing, laboratory, and HVAC installations.
Key electrical characteristics include a capacitance of 68nF and an inductance of 25mH, providing efficient noise attenuation and minimal leakage current of 2.1mA to enhance operational safety.
The device performs reliably within a wide temperature range from -25°C to 100°C, making it suitable for varied environmental conditions. Designed for DIN rail mounting with screw termination for secure installation. Effective suppression of electromagnetic interference in industrial control panels.
Compact dimensions optimize panel space requirements. Durable metal construction suitable for demanding environments. Broad operating temperature range ensures reliability. Low leakage current enhances safety compliance.
Single phase, single stage filter tailored for AC power lines. Capacitance and inductance values optimized for EMI noise removal.
This RFI filter is essential in industrial electrical systems, manufacturing plants, and other commercial installations where stable AC power and EMI management are critical. View the full range of power line filters for additional options tailored to specific power requirements on EnvMart.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this RFI filter is 20A.
This model operates at a maximum voltage of 250V AC.
It operates efficiently at both 50Hz and 60Hz frequencies.
The dimensions of this filter are 102mm in length, 61mm in depth, and 48mm in height.
The capacitance is 68nF and the inductance is 25mH, which are optimized for EMI suppression.
The leakage current is low at 2.1mA, enhancing safety and compliance.
This filter operates reliably within a temperature range from -25°C to 100°C.
It is designed for DIN rail mounting with screw termination for secure installation.
The filter is constructed with a metal housing, ensuring durability in industrial environments.
This model is suitable for industrial, manufacturing, laboratory, and HVAC installations where EMI management is critical.
This RFI filter belongs to the FMAB RAIL series.
This is a single-phase filter, designed specifically for AC power lines.
