Schurter FMAC RAIL RFI Filter 1A 250V AC 50Hz 60Hz DIN Rail Mount Screw Termination 5500.2263
Specifications
| Country of Origin | India |
|---|---|
| Brand | Schurter |
| Height | 48mm |
| Length | 102mm |
| Depth | 61mm |
| Mount Type | DIN Rail |
| Operating Frequency | 50, 60Hz |
| Series | FMAC RAIL |
| Maximum Operating Temperature | 100°C |
| Number Of Stages | 2 |
| Resistance | 1mΩ |
| Capacitance | 470nF |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 1A |
| Number of Phases | 1 |
| Leakage Current | 250μA |
| Maximum Voltage | 250V ac |
| Inductance | 25mH |
| Standards/Approvals | EN 60950 |
| Termination Style | Screw |
Key Features
- Two stage RFI filter effective in the frequency range of 10kHz to 30MHz.
- Mount type is DIN Rail with screw termination style for secure connection.
- Designed to operate with 50Hz and 60Hz industrial power systems.
- Robust metal housing suitable for electric switch and control cabinets.
- Capacitance of 470nF and inductance of 25mH ensuring effective interference attenuation.
- Leakage current is low at 250μA providing safety and efficiency.
- Maximum operating temperature of 100°C with minimum operating temperature at -25°C.
- Resistance of 1mΩ supporting minimal power loss.
Product Description
Schurter 5500.2263 FMAC RAIL is a high-performance RFI filter designed for DIN rail mounting in industrial applications. With a current rating of 1A and voltage capacity of 250V AC, it ensures reliable suppression of electromagnetic interference in power line systems operating at 50Hz and 60Hz.
This filter is constructed with a two-stage design that effectively attenuates broad band interferences from 10kHz up to 30MHz, providing cleaner power supply in electric switch and control cabinets. The metal housing offers robustness and durability in demanding environments.
Key electrical parameters include a capacitance of 470nF, inductance of 25mH, and leakage current limited to 250μA, maintaining safety and signal integrity. It operates efficiently in temperature ranges from -25°C to 100°C and complies with EN 60950 standards, ensuring quality and safety compliance for industrial equipment.
Mounting is via DIN rail with screw terminations ensuring secure and easy installation. The compact form factor (102mm length, 61mm depth, and 48mm height) optimizes cabinet space. Resistance is kept minimal at 1mΩ for efficient performance.
Two-stage broad band attenuation for EMI suppression. Designed for use in industrial control and switch cabinets. Certified to EN 60950 standard. Suitable for 1-phase power line applications. Compact and robust metal housing with DIN rail mount.
Effective operation in wide temperature range. Low leakage current for safety and performance. Precision electrical characteristics for reliable filtration.
This Schurter FMAC RAIL RFI Filter is ideal for applications requiring effective EMI management in industrial, manufacturing, and commercial electrical systems within power line filters category. Explore EnvMart’s comprehensive selection of EMI and power line filters for your industrial needs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this RFI filter is 1A.
It supports a maximum voltage of 250V AC.
The operating frequency range is designed for 50Hz and 60Hz power systems.
The dimensions are 102mm in length, 61mm in depth, and 48mm in height.
The capacitance is 470nF and the inductance is 25mH.
The leakage current is limited to 250μA.
The minimum operating temperature is -25°C and the maximum is 100°C.
It is designed for DIN rail mounting with screw termination style for secure connection.
It complies with the EN 60950 standard.
This filter features a two-stage design for effective interference attenuation.
The resistance of this RFI filter is 1mΩ, supporting minimal power loss.
It is intended for use in industrial control and switch cabinets, providing effective EMI management.
