ABB System Pro M Compact S200M Miniature Circuit Breaker, 2-Pole, 2A, Type D, 400V AC, 125V DC 2CDS272001R0021 S202M-D2

ABB 2CDS272001R0021 S202M-D2 Miniature Circuit Breaker from the System Pro M Compact series combines advanced overload and short-circuit protection for electrical circuits up to 2 amperes. This 2-pole breaker is designed to operate efficiently at 400V AC and 125V DC, suitable for various industrial and commercial electrical installations.

The device features Type D tripping characteristics, suitable for circuits with high inrush currents, such as large motors and transformers. Its thermal tripping mechanism ensures reliable overload protection, while the electromechanical system guards against short circuits. This enhances operational safety and prevents damage to connected equipment.

Mounting onto DIN rails and utilizing screw terminals with Pozidriv 2 compatibility offers straightforward installation and secure conductor connections. The compact 35mm width fitting in an 88mm height and 69mm depth package optimizes panel space.

ABB’s S200M MCB is engineered with IP20 and IP40 ratings, allowing safe use in diverse environmental conditions. The toggle switch actuator enables clear status indication and quick resetting capability during maintenance or fault clearance.

With a mechanical life expectancy of 20,000 operations and a breaking capacity of 10 kA, this MCB ensures long-term dependable performance and safe interruption of electrical faults. Manufactured in Germany, it complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards, certifying international safety and quality benchmarks.

This miniature circuit breaker is widely used in industrial control panels, automotive workshops, signaling systems, and various other electrical protection applications. Its design focuses on energy efficiency by minimizing power loss to 3.3W.

Equipped with Type D tripping characteristics for handling high inrush currents. Rated for 400V AC and 125V DC operational voltages. Offers a breaking capacity of 10 kA to interrupt significant fault currents safely. Features a toggle switch reset actuator for easy operation.

Compatible with DIN rail mounting and screw-type terminal connections. Designed with thermal tripping mechanism ensuring overload protection. IP20 and IP40 rated for protection in varying environments. Mechanical lifespan of 20,000 cycles for prolonged reliability.

Constructed with a compact 35mm width and durable materials from Germany. Explore more electrical protection solutions in the Miniature Circuit Breaker category at EnvMart for efficient and safe electrical installations.
