ABB System Pro M Compact S200 Miniature Circuit Breaker, 2-Pole, 32A, Type B, 400V ac AC, 125V dc 2CDS252001R0325 S202-B32
Specifications
| Country of Origin | Germany |
|---|---|
| Range | System Pro M Compact |
| Brand | ABB |
| Height | 69mm |
| Model | 2CDS252001R0325 S202-B32 |
| Depth | 69mm |
| IP Rating | IP20, IP40 |
| Width | 35mm |
| Mount Type | DIN Rail |
| Current Rating | 32A |
| Series | S200 |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Standards/Approvals | IEC/EN 60898-1, IEC/EN 60947-2 |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 125V dc |
| Tripping Characteristics | Type B |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Electromagnetic, Thermomagnetic |
| Reset Actuator Type | Lever |
Key Features
- Offers 2-pole configuration for effective circuit interruption.
- Supports up to 400V AC and 125V DC voltage ratings.
- Delivers a high breaking capacity of 10 kA for safety during short circuits.
- Designed for DIN rail mounting with screw terminal connections.
- Incorporates electromagnetic and thermomagnetic tripping mechanisms for accurate protection.
- Complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards.
- Features IP20 and IP40 ingress protection ratings.
- Compact size with 35 mm width, 69 mm height, and 69 mm depth dimensions.
Product Description
ABB 2CDS252001R0325 S202-B32 Miniature Circuit Breaker from the System Pro M Compact S200 series offers advanced circuit protection with a 32 ampere current rating and Type B tripping characteristic suitable for commercial and industrial applications. It supports electrical supply voltages of 400V AC and 125V DC, delivering a breaking capacity of 10 kA to ensure safety against short circuit faults.
This 2-pole MCB is engineered for DIN rail mounting and features screw terminal connections, enabling easy installation and secure electrical contact. It uses a combined electromagnetic and thermomagnetic tripping mechanism that guarantees precise and prompt response to overload and short circuit conditions, preventing potential damage to electrical equipment and installations.
The device complies with internationally recognized IEC/EN 60898-1 and IEC/EN 60947-2 standards, assuring product reliability and quality. With ingress protection ratings of IP20 and IP40, it is well protected from solid object intrusion, making it suitable for various electrical environments.
The compact dimensions of 35 mm width, 69 mm height, and 69 mm depth facilitate integration into electrical distribution boards and panels with space constraints. The reset lever actuator allows easy manual operation for resetting the circuit breaker after a trip event.
This Miniature Circuit Breaker is ideal for protecting circuits in commercial electrical systems, industrial machinery, automation control panels, and distribution boards, enhancing electrical safety and system reliability.
Offers 2-pole configuration for effective circuit interruption. Supports up to 400V AC and 125V DC voltage ratings. Delivers a high breaking capacity of 10 kA for safety during short circuits. Designed for DIN rail mounting with screw terminal connections.
Incorporates electromagnetic and thermomagnetic tripping mechanisms for accurate protection. Complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards. Features IP20 and IP40 ingress protection ratings. Compact size with 35 mm width, 69 mm height, and 69 mm depth dimensions.
Explore more from the Circuit Breakers category on EnvMart for reliable electrical protection solutions suitable for industrial, commercial, HVAC, and manufacturing environments.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 32A.
It supports voltage ratings of up to 400V AC and 125V DC.
The breaking capacity is 10 kA, providing safety during short circuits.
It is designed for DIN rail mounting and features screw terminal connections for secure installation.
It incorporates both electromagnetic and thermomagnetic tripping mechanisms for accurate protection.
The dimensions are 35 mm in width, 69 mm in height, and 69 mm in depth.
It features IP20 and IP40 ingress protection ratings, suitable for various environments.
It complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards.
The tripping characteristic is Type B, suitable for commercial and industrial applications.
It features a lever type reset actuator for easy manual operation after a trip event.
The country of origin for this circuit breaker is Germany.
This model is part of the System Pro M Compact series from ABB.
